Specifications
Brand Name :
CN CABLE
Model Number :
DJYJYP3
Certification :
BS
Place of Origin :
Henan , China
MOQ :
1000meters
Conductor :
Class 1 solid copper conductor according to BS EN 60228 (previously BS 6360) Class 2 stranded copper conductor according to BS EN 60228 (previously BS 6360) Class 5 flexible copper conductor according to BS EN 60228 (previously BS 6360)
Insulation :
MICA Tape + XLPE
Binder Tape :
Polyester Tape
Screen :
aluminum-plastic composite tape
Drain Wire :
Tinned copper
Sheath :
LSZH (Low Smoke Zero Halogen)
rated voltage :
300/500V
Sheath color :
Red , black
Description

BS 5308 XLPE insulation aluminum-plastic composite tape screen with tinned copper drain wire instrumentation cable

CHARACTERISTICS:

Voltage Rating (Uo/U) : 300/500V

Operating Temperature: +90°C

Temperature Rating: 0°C to +50°C

Sheath Colour: Red Black

Date

P=pairs , T=triple , Q=quad

NO. OF
PAIRS/TRIPLE		 NOMINAL CROSS
SECTIONAL AREA
mm²		 NOMINAL OVERALL
DIAMETER
mm
1P
1P
1P
1P
1P
1T
1T
1T
1T
1T
2P(Q)
2P (Q)
2P (Q)
2P (Q)
2P (Q)
5P
5P
5P
5P
5P
10P
10P
10P
10P
10P
15P
15P
15P
15P
15P
20P
20P
20P
20P
20P		 0.5
1
1.5
2.5
0.75
0.5
1
1.5
2.5
0.75
0.5
1
1.5
2.5
0.75
0.5
1
1.5
2.5
0.75
0.5
1
1.5
2.5
0.75
0.5
1
1.5
2.5
0.75
0.5
1
1.5
2.5
0.75		 6.9
7.3
8.5
9.3
7.4
7.3
7.8
9
9.9
8.1
8.2
8.7
9.9
11.1
8.8
14.5
15.4
17.9
20.3
15.6
21
22.3
25.7
28.4
22.7
24.1
25.6
29.6
30.3
26
27
28.8
33.6
37.2
29.3

ELECTRICAL CHARACTERISTICS

NOMINAL CROSS
SECTIONAL AREA
mm²		 MUTUAL CAPACITANCE
pF/m		 MINIMUM INSULATION
RESISTANCE AT 20°C
Gohms/km		 MAXIMUM
L/R RATIO
µH/ohms
Cables with Collective
Screen Only		 1 Pair, 2 Pairs, 1 Triple
Collectively Screened		 Cables with Individually
Screened Pairs
0.5
0.75
1
1.5
2.5		 75
75
75
85
85		 115
115
115
120
120		 115
115
115
120
120		 >5
>5
>5
>5
>5		 25
25
25
40
65

CONDUCTORS

NOMINAL CROSS
SECTIONAL AREA
mm²		 CONDUCTOR
CLASS		 MAXIMUM DC RESISTANCE OF CONDUCTOR AT 20°C
ohms/km
0.5
0.75
1
1.5
2.5		 5
5
1
2
2		 39
26
18.1
12.1
7.41
