0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding
0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding
0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding
0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding
0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding
0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding
0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding
0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding
Specifications
Brand Name :
CN CABLE
Model Number :
J-YY
Certification :
VDE
Place of Origin :
Henan
MOQ :
1000meters
Payment Terms :
L/C, T/T
Delivery Time :
15days after payment
Packaging Details :
Drum
Construction :
Copper bare,solid,0,8mm diameter
Insulation :
PVC
Shielding :
plastic foil
Sheath : :
PVC
certification :
VDE
model :
J-YY
Description

Fire-alarm cable J-YY cable as communication cable for permanent installation making out connection to alarm devices.

Application

As communication cable for permanent installation making out connection to alarm devices. Not to be used for power transmission and laying in the ground.

Construction

Copper conductor: bare solid. 0.8mm

Insulation: PVC

Stranding: plastic foil

Sheath: PVC, color: red RAL 3000

Technical data

Conductor loop resistance:max.73,2Ω/km

Insulation resistance: min.100MΩ*km

Operating capacity(800Hz): max.100Nf/km

Test voltage: 800v 50Hz 1Min.

Peak operating voltage 300v

Temperature range

Flexible: -5℃..50℃

Fixed installation: -30℃…70℃

Minimum bending radius: 7.5*cable diameter

0.8mm Diameter Fire Alarm Cable / Low Voltage Power Cable Plastic Foil Shielding

Section

mm2

Copper content

kg/km
1*2*0.8 10.0
2*2*0.8 20.0
