1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables
1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables
1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables
1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables
1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables
1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables
Specifications
Brand Name :
OEM
Certification :
ISO/RoHS/CE
Place of Origin :
china
MOQ :
200 meters
Payment Terms :
L/C, T/T
Supply Ability :
50000meters per week
Delivery Time :
5-15day
Packaging Details :
wooden drum
Conductor :
Copper or Aluminum
Insulation :
Polyvinyl Chloride (PVC) Insulated
Outer Sheath :
Polyvinyl Chloride (PVC) Sheathed
Armor :
DSTA/SWA/AWA Armored or Unarmored
Rated Voltage :
0.6/1KV
Cross Section Area :
0.75mm2-1000mm2
Standard :
IEC60502, BS IEC ASTM DIN, GB/T12706, VDE, UL
Color :
Black or Customized
Application :
Construction, Industrial, Underground, Power Station
Feature :
Abrasion-resistant
Price :
Negotiable
Description

1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables

Rated Voltage:

0.6/1kv

Number of cores:

1 core, 2 core, 3 core, 3+1 core, 3+2 core, 4 core, 4+1 core, 5 core

PVC Insulated Electrcial Cable Application:

PVC insulated cable is suitable for laying at the fixed places. It is widely used in electric line distribution and power transmission with AC rated voltage up to and including 1KV.

PVC Insulated Electrcial Cable Service Performance:

1) Rated voltage: 0.6/1KV

2) Long-term working temperature: not be higher than 70°C

3) When laying the cable, the ambient temperature should not lower than 0°C

4) Minimum bending radius:

Bending radius≥4D as cable overall diameter≤25mm

Bending radius≥6D as cable overall diameter>25mm

1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables

PVC Insulated Electrical Cable Types:

PVC Insulated Cable Types Description Cores Nomi Section Area
Cu/PVC/PVC copper core, pvc insulated,
pvc sheathed, electric cable		 1 core


2 core


3 core


4 core


5 core


3+1 core


3+2 core


4+1 core		 1.5~1000mm2
Al/PVC/PVC aluminum core, pvc insulated,
pvc sheathed, electric cable
Cu/PVC/STA/PVC copper core, pvc insulated, steel tape armoured, pvc sheathed, electric cable 4~1000mm2
Al/PVC/STA/PVC aluminum core, pvc insulated, steel tape armoured, pvc sheathed, electric cable
Cu/PVC/SWA/PVC copper core, pvc insulated, steel wire armoured, pvc sheathed, electric cable
Al/PVC/SWA/PVC aluminum core, pvc insulated, steel wire armoured, pvc sheathed, electric cable
ZR-Cu/PVC/PVC copper core, pvc insulated, pvc sheathed, flame retardant, electric cable 1.5~1000mm2
ZR-Al/PVC/PVC aluminum core, pvc insulated, pvc sheathed, flame retardant, electric cable
ZR-Cu/PVC/STA/PVC copper core, pvc insulated, steel tape armoured, pvc sheathed, flame retardant, electric cable 4~1000mm2
ZR-Al/PVC/STA/PVC aluminum core, pvc insulated, steel tape armoured, pvc sheathed, flame retardant, electric cable
ZR-Cu/PVC/SWA/PVC copper core, pvc insulated, steel wire armoured, pvc sheathed,
flame retardant, electric cable
ZR-Al/PVC/SWA/PVC aluminum core, pvc insulated, steel wire armoured, pvc sheathed, flame retardant, electric cable


PVC Insulated Electrical Cable Technical Data:

Cross-section of conductor (mm2) Kind of Conductor Insulation Thickness (mm) Sheath Thickness (mm) Average Max. Outer-diameter (mm) Product Approximate weight (kg/km) Conductor copper-wire Max. resistance (Ω/km) Min. insulation resistance (MΩ.km)
Metal coated No metal coated
2×1.5 1 0.7 1.2 10 84.93 12.1 12.2 0.011
2 0.7 1.2 10.5 89.13 12.1 12.2 0.01
2×2.5 1 0.8 1.2 11.5 116.99 7.41 7.56 0.01
2 0.8 1.2 12 124.84 7.41 7.56 0.009
2×4 1 0.8 1.2 12.5 154.02 4.61 4.7 0.0085
2 0.8 1.2 13 162.49 4.61 4.7 0.0077
2×6 1 0.8 1.2 13.5 201.43 3.08 3.11 0.007
2 0.8 1.2 14 211.74 3.08 3.11 0.0065
2×10 1 1 1.4 16.5 342.84 1.83 1.84 0.007
2 1 1.4 17.5 354.15 1.83 1.84 0.0065
2×16 2 1 1.4 20 481.24 1.15 1.16 0.0052
2×25 2 1.2 1.4 24 717.82 0.727 0.734 0.005
2×35 2 1.2 1.6 27.5 955.57 0.524 0.529 0.0044
3×1.5 1 0.7 1.2 10.5 105.86 12.1 12.2 0.011
2 0.7 1.2 11 110.82 12.1 12.2 0.01
3×2.5 1 0.8 1.2 12 149.34 7.41 7.56 0.01
2 0.8 1.2 12.5 159.02 7.41 7.56 0.009
3×4 1 0.8 1.2 13 201.04 4.61 4.7 0.0085
2 0.8 1.2 13.5 211.19 4.61 4.7 0.0077
3×6 1 0.8 1.4 14.5 278.69 3.08 3.11 0.007
2 0.8 1.4 15.5 291.56 3.08 3.11 0.0065
3×10 1 1 1.4 17.5 457.6 1.83 1.84 0.007
2 1 1.4 19.5 472.47 1.83 1.84 0.0065
3×16 2 1 1.4 21.5 652.85 1.15 1.16 0.0052
3×25 2 1.2 1.4 26 985.18 0.727 0.734 0.005
3×35 2 1.2 1.6 29 1316.42 0.524 0.529 0.0044
4×1.5 1 0.7 1.2 11.5 129.92 12.1 12.2 0.011
2 0.7 1.2 12 137.02 12.1 12.2 0.01
4×2.5 1 0.8 1.2 13 185.91 7.41 7.56 0.01
2 0.8 1.2 13.5 199.73 7.41 7.56 0.009
4×4 1 0.8 1.4 14.5 264.06 4.61 4.7 0.0085
2 0.8 1.4 15 280 4.61 4.7 0.0077
4×6 1 0.8 1.4 16 352.25 3.08 3.11 0.007
2 0.8 1.4 17 372.18 3.08 3.11 0.0065
4×10 1 1 1.4 19 589.31 1.83 1.84 0.007
2 1 1.4 20.5 614.24 1.83 1.84 0.0065
4×16 2 1 1.4 23.5 848.16 1.15 1.16 0.0052
4×25 2 1.2 1.6 27.5 1309.68 0.727 0.734 0.005
4×35 2 1.2 1.6 32 1724.19 0.524 0.529 0.0044
5×1.5 1 0.7 1.2 12 155.09 12.1 12.2 0.011
2 0.7 1.2 12.5 163.63 12.1 12.2 0.01
5×2.5 1 0.8 1.2 14 223.98 7.41 7.56 0.01
2 0.8 1.2 14.5 240.8 7.41 7.56 0.009
5×4 1 0.8 1.4 16 319.08 4.61 4.7 0.0085
2 0.8 1.4 17 338.37 4.61 4.7 0.0077
5×6 1 0.8 1.4 17.5 428.24 3.08 3.11 0.007
2 0.8 1.4 18.5 452.4 3.08 3.11 0.0065
5×10 1 1 1.4 21 721.03 1.83 1.84 0.007
2 1 1.4 22 750.19 1.83 1.84 0.0065
5×16 2 1 1.6 26 1063.16 1.15 1.16 0.0052
5×25 2 1.2 1.6 31.5 1612.39 0.727 0.734 0.005
5×35 2 1.2 1.6 35 2127.77 0.524 0.529 0.0044

1.5mm2 2.5mm2 Abrasion Resistant PVC Insulated Cables
