1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
Specifications
Brand Name :
ASIA METAL
Model Number :
201 304 316l 304l 430 439 441 409
Certification :
ISO9001
Place of Origin :
Guangdong China
MOQ :
1 Ton/Sheet
Price :
$1/Tons 1-100 Tons
Payment Terms :
L/C, D/A, D/P, T/T
Supply Ability :
1000000 Tons Per Month
Delivery Time :
15-21 days
Packaging Details :
Standard Sea-worthy Packing
Product Name :
1.2mm stainless steel sheet DQ DDQ
Material :
Stainless Steel
Type :
Sheet
Thickness :
0.3-3mm
Surface :
2B/BA/No.4/HL/Mirror
Width :
1219mm
Edge :
Mill Edge Slit Edge
Price Term :
CIF CFR FOB EX-WORK
Payment Term :
30%T/T Advance + 70% Balance
Description

sus 201 304 316l 304l 430 439 441 409 1.2mm stainless steel sheet DQ DDQ

What is Stainless Steel ?
Stainless steel contains chromium which provides the properties of corrosion resistance at high temperatures. Stainless steel can withstand corrosive or chemical environments due to its smooth surface. Stainless steel products are safe for long-term use with excellent resistance of corrosion fatigue.

Stainless Steel Sheet Information
Technique Surface Finish Grade Series Thickness(mm) Width(mm) Application
Main Dimension
20-850 1000 1219 1240 1250 1500 Petro-chemical industry,Tanks
Construction material
Hot Rolled No.1 / 2E 201/202/
304		 2.2-12.0 √ √ √ √ √
Cold Rolled 2B 201/304 0.25-3.0 √ √ √ √ √ √
410S/430 0.25-2.0 √ √ √ √
No.4 / Hairline
Mirror / Linen
SB		 201/304 0.22-3.0 √ √ √ √ √
410S/430 0.25-2.0 √ √ √ √ √
BA 201/304 0.2--1.8 √ √ √ √
410S/430 0.25-2.0 √ √ √ √
2BA √ √ √ √

Chemical composition and mechanical properties of stainless steel coils
Grade Chemical Composition (%) Mechanieal Performece
C Si Mn P S Ni Cr Mo Hardness
201 ≤0.15 ≤1.00 5.5/7.5 ≤0.060 ≤0.030 3.5/5.5 16.0/18.0 - HB≤241,HRB≤100, HV≤240
304 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 8.0/11.0 18.00/20.00 - HB≤187,HRB≤90,HV≤200
316 ≤0.08 ≤1.00 ≤2.00 ≤0.045 ≤0.03 10.00/14.00 16.0/18.0 2.00/3.00 HB≤187, HRB≤90 HV≤200
316L ≤0.03 ≤1.00 ≤2.00 ≤0.045 ≤0.03 10.00/14.00 16.0/18.0 2.00/3.00 HB≤187, HRB≤90 HV≤200
410 ≤0.15 ≤1.00 ≤1.25 ≤0.060 ≤0.030 ≤0.060 11.5/13.5 - HB≤183, HRB≤88 HV≤200
430 ≤0.12 ≤1.00 ≤1.25 ≤0.040 ≤0.03 - 16.00/18.00 - HB≤183, HRB≤88 HV≤200

Packing details

1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409

1 Sheets covered with wooden plate for protection in transportation.
2. All sheets will be loaded in strong wooden packages.
3. Every cartons loaded with good shoring and strengthening.
4. Take container loading pictures and seal the container.
5. Transportation speed is quick. And keep customer each step informed.

1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409

What is 2B ?
2B Finished by heat treatment , picking or equipvalent cold rolling , followed by skin pass to obtain adequate luster surface.

1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409

What is BA ?
BA surface finished is Bright heat treatment after cold rolling.

1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409

What is NO.4 ?
No.4, also called #4, satin or directional finish, is an unidirectional finish obtained with a 100-400 grit abrasive depending on requirements. High grit numbers create finer polishing lines and more reflective finishes.
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
What is Hairline finished ?
Hairline referred to as "the HL",it’s grain as fine as hair, straight and continuous, delicate with oil paints on the surface. It has slightly lower reflective rate than satin stainless steel sheet.
1.2mm 202 304L Stainless Steel Sheet Mill Edge DQ DDQ SUS 316L 430 439 441 409
What is Mirror finished ?
Mirror finish is produced by progressively using finer abrasives and finishing with extremely fine buffing compounds. Mirror finish is also called 8K, No.8 and polish finish, which is the most reflective mirror finish with high quality to similar as glass mirror. The final surface is blemish free with a high degree of image clarity and is the true mirror finish.
