25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370
Specifications
Brand Name :
Aslong
Model Number :
JGA25-370
Certification :
ROSH ,CE
Place of Origin :
China
MOQ :
100
Price :
USD4.3/pcs
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
10000pcs/Week
Delivery Time :
5-8 working days
Packaging Details :
bubble + carton
Usage :
Car,Electric Bicycle
Commutation :
Brush
Speed(rpm) :
5RPM-1500RPM
Type :
Gear Motor,mini 12v dc gear motor
Protect feature :
Totally Enclosed
Torque :
0.2kg.cm~5kg.cm
Efficiency :
IE 1
Voltage(v) :
12-24V
Product name :
12V Strong Magnetism DC Gear Motor With Eccentric Shaft
Material :
Stainless Steel
Shaft diameter :
8MM
Description

25mm 1600RPM Electric DC Gear Motor High Torque High Rpm JGA25 370

25mm Diameter 1600RPM Low Noise Long Life JGA25-370 High Torque High Rpm 3V 6V 12v 24V Dc Geared Motor 12V For Robot Car

Features:
1. Motor type: Brushed DC motor
2 .Gearbox: Spur gearbox
3. Voltage: 3V, 4.5V, 5V, 6V, 7.2V, 9V, 12V, 24V DC
4. Speed: 5RPM-1500RPM
5. Torque: 0.2kg.cm~5kg.cm
6. Shaft dia: 4mm
7. Direction: CW/CCW
8. Typical application: Electric lock system, Valve, Vending machine, Pumps, Beauty apparatus, Vending machinie, DIY robot toys, Paper shredders, Boat motors, Power tools
9. Customized service: Motor's performance parameter, Shaft type, Wires and connectors, Encoders

Model No load Rated Stall Weight

Length
Rated voltage Speed Current Speed Current Torque Torque Current
V RPM A RPM A KG. CI KG. CM A g mm
JGA25-37O-4. 4K 6 1360 0.1 1046 0.5 0.07 0.4 2.6 83 18
JGA25-370-9. 6K 6 620 0.1 477 0.5 0.16 0.9 2.6 83 17.5
JGA25-370-21.3K 6 280 0.1 215 0.5 0.35 2 2.6 86 19
JGA25-370-35. 5K 6 170 0.1 131 0.5 0.6 3.3 2.6 88 21
JGA25-370-46. 8K 6 130 0.1 100 0.5 0.8 4.4 2.6 88 21
JGA25-370-78K 6 77 0.1 59 0.5 1.3 5.5 2.6 90 23
JGA25-370-103K 6 60 0.1 46 0.5 1.7 7.3 2.6 90 23
JGA25-370-130K 6 46 0.1 35 0.5 2.2 9.1 2.6 89 25
JGA25-370-171K 6 35 0.1 27 0.5 2.9 Ban stall 89 25
JCA25-370-226K 6 26 0.1 20 0.5 3.8 89 25
JGA25-37O-377K 6 16 0.1 12 0.5 6.3 91 27
JGA25-370-500K 6 12 0.1 9 0.5 8.3 91 27
Model No load Rated Stall

Weight

 L(size)
Rated voltage Speed Current Speed Current Tcxque Torque Current
V RPM A RPM A KG. CM KG. CM A g MM
JGA25-370-4. 4K 12 1360 0.07 1046 0.3 0.1 0.4 1.8 83 18
JCA25-37O-9. 6K 12 620 0.07 477 0.3 0.2 0.9 1.8 83 17.5
JCA25-370-21. 3K 12 280 0.07 215 0.3 0.4 2 1.8 86 19
JGA25-370-35. 5K 12 170 0.07 131 0.3 0.69 3.3 1.8 88 21
JGA25-370-46. 8K 12 130 0.07 100 0.3 0.9 4.4 1.8 88 21
JGA25-370-78K 12 77 0.07 59 0.3 1.5 5.5 1.8 90 23
JCA25-370-103K 12 60 0.07 46 0.3 2 7.3 1.8 90 23
JGA25-370-130K 12 46 0.07 35 0.3 2.5 9.2 1.8 89 25
JCA25-370-171K 12 35 0.07 27 0.3 3.3 Ban stall 89 25
JCA25-37O-226K 12 26 0.07 20 0.3 4.4 89 25
JCA25-37O-377K 12 16 0.07 12 0.3 7.3 91 27
JGA25-370-500K 12 12 0.07 9 0.3 9.7 91 27
Model NoloX R*d Stall

Weight

 Lsize
Rated voltage Speed Current Speed Current Tcxque Torque Current
V RPM A RPM A KG. CI KG. CM A g MM
JCA25-370-4. 4K 24 1360 0.04 1046 0.16 0.1 0.4 0.6 83 18
JCA25-37O-9. 6K 24 620 0.04 477 0.16 0.2 0.9 0.6 83 17.5
JGA25-370-21.3K 24 280 0.04 215 0.16 0.4 2 0.6 86 19
JCA25-370-35. 5K 24 170 0.04 131 0.16 0.69 3.3 0.6 88 21
JGA25-370-46. 8K 24 130 0.04 100 0.16 0.9 4.4 0.6 88 21
JGA25-370-78K 24 77 0.04 59 0.16 1.5 5.5 0.6 90 23
JCA25-370-103K 24 60 0.04 46 0.16 2 7.3 0.6 90 23
JCA25-370-130K 24 46 0.04 35 0.16 2.5 9.2 0.6 89 25
JCA25-37O-171K 24 35 0.04 27 0.16 3.3 Ban stall , 89 25
JGA25-37O-226K 24 26 0.04 20 0.16 4.4 89 25
JGA25-37O-377K 24 16 0.04 12 0.16 7.3 91 27
JGA25-370-500K 24 12 0.04 9 0.16 9.7 91 27

FAQ
1. who are we?
We are based in Guangdong, China, start from 2005,sell to North America(30.00%),Domestic Market(15.00%),Western Europe(10.00%),Eastern Europe(10.00%),Northern Europe(6.00%),Southern Europe(5.00%),Southeast Asia(5.00%),South America(5.00%),Oceania(5.00%),South Asia(4.00%),Africa(3.00%),Eastern Asia(2.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3. what can you buy from us?
Gear Motor,DC Motor,Brushless Motor,Planetary Gear Motor,Worm Gear Motor

4. why should you buy from us not from other suppliers?
Specialized in Micro DC motor, Dc Gearbox motor.We have been in this industry for over 10 years,we have many experinec to provide motors according to customer's requirements.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FCA,Express Delivery；
Accepted Payment Currency:USD,EUR,HKD,CNY;
Accepted Payment Type: T/T,L/C,D/P D/A,Credit Card,PayPal;
Language Spoken:English,Chinese
