ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster
ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster
ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster
ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster
ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster
ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster
ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster
ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster
Specifications
Brand Name :
DY
Model Number :
Customized
Certification :
ISO9001
Place of Origin :
Zhejiang, China (Mainland)
MOQ :
Negotiation
Price :
Negotiation
Payment Terms :
L/C, T/T, MoneyGram, Western Union
Supply Ability :
10000 Sets per Month
Delivery Time :
15 days
Packaging Details :
Standard packing
Type :
with brake
Color :
as your requirment
Size :
3/4 inch
Diameter :
75mm（3＂）/100mm（＂）
Material :
ESD
Model :
PZ-SC-3-ESD/PZ-SC-4-ESD
Description

ESD Medical Caster Square Stem Type with Brake Caster (Black)

Description:

TPE/TPR has rubber elasticity and plastic properties, which can make casters more durable, with impact resistance.

In addition, it has excellent weather resistance, low temperature, chemical resistance, and waterproof, steam and puncture resistance.

It is superior to natural rubber and TPU in processing.

It successfully solves the defects of injection molding and is easy to produce bubbles. It has been adopted by a famous American caster manufacturer. Our company has high elastic wear level. The general-purpose wear-resistant and general-purpose three types of materials meet the requirements of different products and are highly competitive.



Parameter:

Anti-static flat casters length width loading material bearing Floor Size Floor bore distance Floor bore
diameter		 height Radius of
rotation
3 inch D75 30 70 Anti-static ball 94*62 74*45 8.4 105 75
4 inch D100 30 80 ball 94*62 74*45 8.4 130 84
5 inch D125 30 100 ball 94*62 74*45 8.4 157 103
usage:lean tube circulation cart,lean tube shelf,lean tube workbench,production line,etc
brand: Diya
product name: ESD Medical Caster Square Stem Type with Brake Caster (Black)


Brand Diya
Product Name ESD Medical Caster Square Stem Type with Brake Caster (Black)
Diameter 75mm(3＂)/100mm(4＂)
Model PZ-SC-3-ESD/PZ-SC-4-ESD
Installation height 105mm/130mm
Bearing 95KG/100KG
Material ESD
Castor width 32mm




ESD Medical Industrial Caster Wheels Square Stem Type with Brake Caster


Application:

1. production line dollies & trucks

2. used in various industries including but not limited to:
3. boat & ship molding

4. Assembly

5. Automotive

6. Aerospace

7. metal fabricating,heavy machinery

8. military equipment

Advantages:

1. No noise interference, excellent wear resistance and reverse elasticity

2. High tear resistance, high Elongation at break is dust-free, anti-static, conductive.

3. Without no traces on the floor, no rubber wheels will have sulfur and carbon black precipitation, good weather resistance.

4. Allowing long-term use temperature range between -50 ~ 115 °C

5. High load (25-500kg), high wear resistance, high rebound C70% or more back-elasticit

6. PP with pole Good adhesion, can pass the US ICM standard caster life test excellent safety

7. Hygienic performance, has passed ROHS, PAHs test, in line with EU environmental requirements.
