Specifications
Brand Name :
WINCOR
Model Number :
1750171633 / 01750171633
Certification :
CO
Place of Origin :
Germany
MOQ :
1pc
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
100pcs in stock
Delivery Time :
1day
Packaging Details :
Natural packing or according to customer's requirement
Warranty :
90 Days/3months
Condition :
Original New/REF original
Product name :
Wincor C4060 Cineo display
Used in :
WINCOR C4060
Material :
Liquid crystal display is an active matrix liquid crystal display driven by means of thin film transistors
Shipment :
DHL Fedex UPS TNT, By Express/by sea/by air, By Express/ Air/sea, Express, By sea
After-sales service provided :
Online support, Video technical support
lead time :
In stock
Description

1750171633 WINCOR ATM Parts MONITOR 15" TFT LED HIGHBRIGHT Display

1750171633 WINCOR ATM Parts MONITOR 15" TFT LED HIGHBRIGHT Display

  • Monitor Description
The monitor includes a TFT (thin film transistor) active matrix LCD panel; AUO G150XG01;
and two LED rail and LED drivers to drive the backlight to a typical surface luminance of 2,000
nit. The 15” display area contains 1024 x 768 pixels and can display 16.2 mil colours.
This is a CLASS 1 LED PRODUCT.
Version 03 :
Base model with LCD cooling managed internally by three fans to control the LCD surface
temperature, located on the top rear of the monitor.
  • Parameter Specification
Description 15” WINCOR High
Bright LED (With
Genesis Controller)
GDS Part No. G1500066
Customer Part No. 01750171633
Issue Level 3
Parameter Module size
Module size 329 (W) x 260.5 (H) x 76.9 (D)mm
Panel Technology TFT (Thin Film Transistor)
Active Area 304.1 (H) x 228.1 (V) mm
Number of pixels 1024 (R,G,B x 3) (H) x 768 (V) PIXEL
Pixel pitch 0.297 (H) x 0.297 (V) mm
Pixel arrangement RGB Vertical Stripe
Display Mode Normally white
Surface treatment Antiglare and hard coating 3H
Number of Colours 16.2 mil

  • Optical Characteristics (AUO G150XG01)
Parameter Unit Min Typ Max note
Screen Brightness Peak (max) Cd/m2 1700 2,000 7
Screen Minimum Brightness Cd/m2 250
Colour Temperature and co ordinates (LEDs + LCD panel) K
x
y		 0.304
0.342		 5,800
0.324
0.362		 0.344
0.382		 8
9
BLU lifetime at 25oC (Full
Brightness)		 Hours >100,000 1
Operating Temperature (Ambient) oC 0 25 60
Option 1:-
Power Consumption at 25oC from:-
24V DC supply (<1.8A)
12V DC supply (<1.7A)		 Watts 43.2
20.4		 2
Option 2:-
Power Consumption at 25oC from:-
12V DC supply (<4.0A)		 Watts 48 2
Viewing Angle
CR>/= 10		 Horizontal (a) Deg. 60 70 3
Horizontal (b) Deg. 60 70 3
Vertical (c) Deg. 55 65 3
Vertical (d) Deg. 50 60 3
Contrast Ratio - 400 750
Response time (Tr + Tf) ms 16
Uniformity % 70 >80 5
MTBF (excluding back light) hours 89,103 6
Note [1] LED lifetime at 25oC ambient to 50% of the original brightness. Condition: Normal
operation 2000 nits for 24hrs per day.
Note [2] Results obtained with GDS LEDs running at maximum output and fans running at
maximum speed. Results will vary with temperature and ambient light. Note display
shall accommodate both Option 1 & 2 power inputs.
Note [3] See Fig. 1 Viewing Angle
Note [4] Contrast Ratio = Luminance with all pixels white/ Luminance with all pixels black.
See Fig. 3
Note [5] Uniformity = (Lmin/Lmax). See Fig. 2
Note [6] Calculated at 25oC Refer to MTBF00004 for further information. This is a nominal
figure.
Note [7] Luminance boost option only available if power consumption can be >48W.
Note [8] Typical CRI for Cool White LEDS (3,700 K – 10,000 K CCT) is 75.
Note [9] The target numbers in the specification for x and y values will be revised once
production has started and more information is available on the component tolerances.
  • Company Profile

TS TECH (HONG KONG) CO.,LTD founded in 2003 in China,is a leading professional supplier of ATM modules and spares, and help hundreds of customers from around the world to source their NCR, Wincor,Diebold,hyosung,GRG parts.

TS TECH (HONG KONG) CO.,LTD has a professional sales and technical team.Most of our sales have more than 10years experience in ATM industry.Our sales know exactly what machine are used in each Market. They are also experienced in importing&exporting from each country.

It can save your communication times.

Our technical team consists of four members. We have top technicians for every brand.As all of them have years of working experience in manufacturers such as wincor diebold NCR hyosung.They can give you technical support.

We are a direct manufacturer in atm spare parts.our factory located in Guangzhou.TS also have good relationships with original manufacturer.we can get new original parts from manufacturer.

I trust TS can give you good support!

  • Product Detail
1 1750044672 V Module Side Guard Plate
2 1750041948 CMD-V4 38t 49t Gear
3 1750109641 1750192140 Wincor Red Puller V Module Shaft
4 1750041947 Wincor Nixdorf Clutch Assembly For 2050 XE. Magneta 24V
5 1750044668 Measuring Station Sensor Holder Ceramic Assd
6 1750041952 GEAR WHEEL G26 26T
7 1750041951 V Module 25T Gear
8 1750041950 GEAR WHEEL G17 17T
9 1750042174 GEAR WHEEL G19 19T
10 1750035778 DRIVE ROLLER SHAFT CMD V4 ASSY
11 1750035768 THICNESS MEASURING SHAFT ASSY
12 1750020811 Counter rotat shaft assy
13 1750035275 V Module Roller with 3 Wheel Shaft Assy
14 1750035776 DRIVE SHAFT CMD V4 ASSY
15 1750035773 Wincor Nixdorf CASH GUIDE XE
16 1750041251 Wincor Nixdorf Flat Belt, double extractor
17 1750035775 DOUBLE EXTRACTOR CHASSIS 01750035775
18 1750050076 Double Extractor Selenoid
19 1750035761 DOUBLE EXTRACTOR CHASSIS 01750035761
20 1750044604 MAGNET SUPPORT MDMS ASSD
21 1750051760
22 1750052437/1750051784/1750062190
