Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz
Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz
Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz
Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz
Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz
Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz
Specifications
Brand Name :
ATNJ
Model Number :
LPDA2
Certification :
CE,ROHS，CCC，TUV,BV， ISO
Place of Origin :
China
MOQ :
1
Price :
USD+10--13+unit
Payment Terms :
T/T, Western Union,Paypal,Alibaba,Bank transfering.
Supply Ability :
1000+unit+per day.
Delivery Time :
3-5 work days
Packaging Details :
Standard neutral packing3.5x3.5x3.5cm(1pcs),
Impedance :
50OHm
RF Connect Type :
N Female
Weight :
0.65 kg
Material :
Zinc Alloy
Gain :
12dBi
Packing size :
45*23*7cm
Frequency :
700-2700MHz
Color :
Whilte
Length :
41cm
Products type :
signal amplifier 4g
Description

Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz

700 - 2700MHz Outdoor Log Periodic Antenna 12dBi For Mobile Phones Signal Repeater

A log-periodic antenna (LP), also known as a log-periodic array or log-periodic aerial, is a multi-element, directional antenna designed to operate over a wide band of frequencies. It was invented by John Dunlavy in 1952.
The most common form of log-periodic antenna is the log-periodic dipole array or LPDA, The LPDA consists of a number of half-wave dipole driven elements of gradually increasing length, each consisting of a pair of metal rods. The dipoles are mounted close together in a line, connected in parallel to the feedline with alternating phase. Electrically, it simulates a series of two or three-element Yagi-Uda antennas connected together, each set tuned to a different frequency.
LPDA antennas look somewhat similar to Yagi antennas, in that they both consist of dipole rod elements mounted in a line along a support boom, but they work in very different ways. Adding elements to a Yagi increases its directionality, or gain, while adding elements to a LPDA increases its frequency response, or bandwidth.
Specification
Item
Specifications
WIFI&GSM Antenna
Frequency Range
700~2700MHz
Polarization
Linear
Gain
12dBi
V.S.W.R
＜2.0
Impendance
50Ω
Mechanical
Cable
RG58
Connector
N/SMA/or others
Radome Material
ABS
Mounting Method
Screw
Environmental
Operating Temperature
-40℃~+85℃
Relative Humidity
Up to 95%
Environmentally Friendly
ROHS Compliant

Further detail pls click here for downloading the products specification:
ATNJ Mobile Signal Repeater.pdf

Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHzOutdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz

Outdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHzOutdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHzOutdoor Log Periodic 12dBi Signal Booster Antenna 700MHz To 2700MHz

FAQ:

Q1 : Are you trading company or manufacturer ? Could I use our own logo and label?

A1 : We are factory, with trading service. We provide OEM/OEM service.

Q2 : Can I have a sample order? What is your MOQ?
A2 : Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

Q3 : Is it easy to set up your items?
A3 : Yes. We have a user manual and support technical support 24/7.

Q4 : What is your warranty time?
A4 : We promise 1 year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.

Q5 : What is your payment terms?
A5 : We accept Alibaba Trade Assurance, T/T, West Union, Paypal, Bank Account Transfering.
