2G 3G 4G 5G Cell Phone Signal Booster Custom 800MHz 900MHz 2600MHz
2G 3G 4G 5G Cell Phone Signal Booster Custom 800MHz 900MHz 2600MHz
2G 3G 4G 5G Cell Phone Signal Booster Custom 800MHz 900MHz 2600MHz
2G 3G 4G 5G Cell Phone Signal Booster Custom 800MHz 900MHz 2600MHz
Specifications
Brand Name :
ATNJ
Model Number :
AT-37-L8GL26
Certification :
CE,ROHS，CCC，TUV,BV， ISO
Place of Origin :
China
MOQ :
5Pcs
Price :
USD+1100--2500+kit
Payment Terms :
T/T, Western Union,Paypal,Alibaba,Bank transfering.
Supply Ability :
1000+unit+per day.
Delivery Time :
3-5 work days
Packaging Details :
Standard neutral packing
Material :
Zinc Alloy ,Plastic
800MHz Frequency Range :
832-862MHz / 791-821MHz
Booster Bandwidth :
Wide Range
Support network :
2G, 3G, 4G, 5G Voice
900MHz Frequency Range :
890-915MHz / 935-960MHz
Booster Warranty :
36 Months
2600MHz Frequency Range :
2500-2570MHz / 2620-2690MHz
Products Type :
Signal Booster 5G, 4g anten
Description

2G 3G 4G 5G Cell Phone Signal Booster Custom 800MHz 900MHz 2600MHz

2G 3G 4G 5G High Gain 800/900/2600MHz Signal Booster 5 Watt Customized Signal Amplifier

Product Detail:

Model No : AT-37-L8GL26

With ALC AGC Function

Can control gain automatically. Avoid base station interference

(Band 20) 800MHz -- Uplink frequency : 832 - 862MHz / Downlink frequency : 791 - 821MHz
(Band 8) 900MHz -- Uplink frequency : 890 - 915MHz / Downlink frequency : 925 - 960MHz

(Band 7) 2600MHz -- Uplink frequency : 2500 - 2570MHz / Downlink frequency : 2620 - 2690MHz


Network support : 2G 3G 4G 5G Voice


Gain : 90dB

Output power : 5watt


Power Supply : AC110V～220V; DC+24V 5A


Connector Type : N-F

Wide Range .

Single Band Repeater with AGC/MGC

Device Model

AT-MS-880/900/1800

Frenquecy Range 1

UplinK: 832-862MHz Downlink: 791-821MHz

Frenquecy Range 2

UplinK: 890-915MHz Downlink: 925-960MHz

Frenquecy Range 3

UplinK: 2500-2570MHz Downlink: 2620-2690MHz

Working System

Band20 800MHz; Band8 900MHz; Band7 2600MHz

Gain

85dB

Device Output Power

37dBm

Bandwidth

Wide Range

Ripple in Band

≤4dB

Noise Figure @ Max.Gain

≤6dB

V.S.W.R

≤2dB

MTBF

>50000Hours

Power Supply

AC110V～220V;DC+24V5A

Power Comsumption

<20W

Impedance Matching

50ohm

Mechanical Specification

RF Connector

N/F

Cooling

Heatsink Convection Cooling

Dimension

170*130*26(mm)

Net Weight

0.35KG

Installation Type

Wall Installation or Desk

Environment Conditions

IP55X

Origin

Shenzhen

Operating Temperature

-10°C~55°C

Further detail pls click here for downloading the products specification:

Selling Point

1. Intelligent to guide the installation with LCD
2. Real time display the signal strength.
3. Automatic dormancy when no user make the calling
4. Automatic alarm when installation mistake and provide the according solution
5. Automatic adjust the system gain to avoid the repeater self-excitation
6. Initiative reminding when the device was damaged.

Free Frequency Combination:
Band 800 : Uplink : 824 - 849 MHz Downlink : 869 - 894 MHz (B20 800 available )
Band 900 : Uplink : 880 - 915 MHz Downlink : 925 - 960 MHz
Band 1800 : Uplink : 1710 - 1785 MHz Downlink : 1805 - 1880 MHz
Band 1900 : Uplink : 1850 - 1910 MHz Downlink : 1930 - 1990 MHz
Band 2100 : Uplink : 1920 - 1980 MHz Downlink : 2110 - 2170 MHz
Band 2300 : Uplink : 2305 - 2315 MHz Downlink : 2350 - 2360 MHz
Band 2600 : Uplink : 2500 - 2570 MHz Downlink : 2620 - 2690 MHz

Band Options : Single Band, Dual Band, Tri Band, Four Band, Free combinations


Output Power : 5W/10W/20W

Power Supply : AC adapter

Size : 308*219* 135mm
Weight : 7.0kg

Please Check Frequency before Buying How to check?

- Android mobile phone
Download App called < Network Cell Info Lite >
The App will tell the number of LTE band


- Iphone
Dial *3001#12345#*
Clink Cell Serving Info
Check Freq Band Indicator, the number is LTE Band

2G 3G 4G 5G Cell Phone Signal Booster Custom 800MHz 900MHz 2600MHz

FAQ:

Q1: Do you have CE or any other certification?

A: Yes,we CE, , ROHS certification,etc.

Q2: Can you give me a discount?

A: Please discuss with our sales.

Q3: What is our Payment methods ?

A: We agree T/T, Western Union, PayPal.L/C for old customers .

Q4: How about gain and output power of your device?

A: Different models, gain and output power are different,for more details, please contact us.

Q5: Can I use your device in suburbs or remote areas?

A: Yes, as long as you can find a good signal source, our signal booster can help you solve signal problems in remote areas.
