High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler
High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler
High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler
High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler
High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler
High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler
Specifications
Brand Name :
VISSONIC
Model Number :
VIS-PHD1616
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
T/T
Delivery Time :
5-8working days
Supply Ability :
10000
Packaging Details :
carton
warranty :
3 years
Input :
HDMI
Output :
HDMI
Control way :
Front panel,RS-232,TCP/IP
Description

High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler

Overview:
PHD series HDMI matrix is professional switcher routs UHD 4Kx2K HDMI signals to any outputs in need.
It provides high peak data transfer rate and perfectly supports synchronous switching of HDMI signals, the robust industrial design makes it able to be a signal management center for high definition signal transmission. It can be widely used in command control center, multi-screen systems, conference room, high definition medical or education teaching etc.

Features

1.High speed switching

2.Resolution is up to 4Kx2K at 30Hz.

3.Support 3D video

4.Support HDMI1.4.

5.Control way is front panel,RS-232,TCP/IP.

6.EDID reading function to fix any compatible problems.

7.Built-in varied of control protocols to work with control system, like AMX,CRESTRON,VISSONIC.

8.The firmware can be updated by the TCP/IP and be convenient for remote support and OEM the special features.

9.Input distance is up to 30m(98 feet)

10.Powerful memory support to preset and call switching mode. With power-down memory function, with power-off site protection;

11.2U standard housing with rack-mounting design

High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler

Model VIS-PHD1616
Specification Input/output support 16 channels
Input HDMI
Output HDMI
Control way Front panel,RS-232,TCP/IP
Resolution Up to 4k x 2k(4096×2160 )
HDMI version HDMI 1.4,Support 3D TV
HDCP Compliant to HDCP 1.4
Hot plug Support plug and play
Input cable Up to 30m(98 feet)
Output cable Up to 15m (50 feet)
HDMI input/output interface Type A, 19 pin, female
Power supply 110~220 VAC
Environment Storage and Work Temperature: -20°~+70°C; humidity:10%~90%
Weight 7KG
Consumption 20W
Dimension(WxDxH) 2U(440mmx333mmx88mm)
Warranty

3 years

High Speed Switching Hdmi Matrix Switcher UHD4Kx2K HDMI 16x16 Seamless Switcher Scaler
