Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits
Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits
Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits
Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits
Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits
Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits
Specifications
Brand Name :
YingMi
Model Number :
008A
Certification :
CE,RoHs
Place of Origin :
China
MOQ :
1pcs
Price :
negotiation
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
10000pcs for one month
Delivery Time :
3-7 days
Packaging Details :
packed in carton box
Brand :
YingMi
Channel quantity :
158
Receiving sensitivity :
-110dBm
Frequency response :
20Hz-18KHz
Weigh :
50g
Dimensions :
65*50*17mm
Mirror harmonic :
>75dB
Warranty :
2 years
Working current :
≤30~80mA
Working frequency :
796-821MHz
Description

Guide Equipment For Factory Visits, With A Frequency Response Of 20Hz-18KHz

The 008A explaining device is a sound-transmitting intelligent electronic device, which is generally used for team reception, and can be used when someone leads a team to visit. Of course, 008A can also be used in education training or government-enterprise meetings, and one person speaks, and hundreds of people listen to it, and there will be no cross-frequency interference between each other, and there will be no interference problems.
Product Specification:
Name Value
Working frequency: 796-821MHz. Other frequecny can be customize
Channel quantity: 158(high frequency 100+Low frequency 58),
Different frequency different channel quantities;
Receiving sensitivity: -110dBm(typical);
Working voltage: 3.0-5.0VDC,recycle polymer lithium battery;
Input: Input(Transmitter):3.5mm microphone;
Output: Output(receiver):3.5mm headphone
Oscillator: PLL;
Second harmonic trap: >40dbc;
Frequency response: 20Hz-18KHz;
Signal to Noise Ratio: 80dB(typical);
Image reject: >80dB;
Mirror harmonic: >75dB;
Separation factor: 70dB(typical);
Frequency offset: <3k;
Distortion factor: <1%;
Oscillation frequency: +/-2ppm;
Working current: Transmitter:≤30~80mA;Receiver:≤50mA;
Working distance: >=250m;
Working temperature: -20℃—+70℃;
Dimensions: 65*50*17mm;
Weight: 50g(battery included);

Product feature:

1. Many channels:dual channel 100 channels;

2. Far transmission distance:open field >= 250m;

3. The through wall effect is good:through concrete wall, brick wall penetration effect;

4. The transmission effect to international level,the leading domestic:Using core technology sound processing, perennial export Europe and the United States and other countries!

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Application:

Tour guide
When a guide leads tourists, it is natural to have situation crowded and noisy among tourists.When this situation happens, it isn’t comfortable for tourists to use the heavy and complicated guide devices. Additionally, our product can be made for tourists to concentrate on the tour and for a guide to make a tour successfully.

Simultaneous interpretation
Have you ever experienced to use simultaneous interpretation devices which are difficult and complicated? Our product is direct and convenient product adapted in the international interpretation. It is used in international conference, church, religious charities and so on.

Reception of the inspection
In case of visiting tour like factories, docks and manufacturing companies, there are a lot of inner noisiness. Therefore, it is hard for a guide to lead the group there. If a guide uses our product in this situation, he doesn’t have to divide the group and can provide exact guidance even the big group. Also, our product makes the image of a company to be enhanced and provides impressing tour with using specific guide devices.

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Recommended Accessories:

Microphone

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Mono headphone

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Charger (1 for 10)

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Charging box

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Packaging & Shipping:

Packing

Packaging Details: Standard export packing. One unit with one independent box.

Shipping

DHL/FedEx/UPS/EMS: 3-7 workdays

Frequency Response Of 20Hz - 18KHz Guide Equipment For Factory Visits

Our Service:

Customized Logo
Free logo printing will be offered if order quantity is above 300pcs.

Our Warranty
2 Years warranty for all Transmitter & Receiver.

Spare Parts

A proportion of spare parts will be shipped along with formal orders.
