Specifications
MOQ :
1 unit
Brand Name :
BIG AUTO
Model Number :
DLX-B03
Place of Origin :
CHINA
Price :
USD5,000 - USD 6,000/ Per Unit
Payment Terms :
L/C, T/T
Supply Ability :
5000-30000units
Delivery Time :
45-60 Working days
Packaging Details :
Using Carton, fumigated wood pallet and steel pallet
Product Name :
Mini Truck DLX-B03
Overall length :
4400
Overall width :
1528
Overall height :
1832
Wheelbase :
2740
Minimum turning radius :
5.5
Curb weight :
930
Gross vehicle weight :
1920
Engine Type :
K14B-A
Piston displacement :
1372
Description

High Safety Big Capacity Mini Truck DLX-B03 1.5 Tons Capacity Gasoline Durable Truck

DLX-B03 General Description:
Body appearance: the vehicle is 4.4 meters long, 1.528 meters wide and 1.832 meters high. The wheelbase is 2.74 meters. The single cab can take two people, and the maximum cargo capacity is up to 1.5 tons.

Power: The engine displacement is 1.372 liters, equipped with a 37-liter mailbox. Maximum speed is 130 km/h. Compression ratio is 9.5.


Safety: All seats are equipped with 3-point seat belts and the vehicle is equipped with steering column, face beams, front disc and rear drum brakes, 9'' booster + LSPV, load-sensing pressure proportional valve, steering lock and power steering + power windows.

DLX-B03 Parameters

DLX-B03 Parameters
Body & Chassis
Overall: L * W * H (mm) 4400*1528* 1832
Interior size of cargo box: L* W * H (mm) 2507*1417*344
Wheelbase (mm) 2740
Tread : Front and Rear (mm) 1310/ 1310
Minimum turning radius 5.5
Curb Weight (kg) 930
Gross Vehicle Weight (kg) 1920
Seating 2
Engine
Type K14B-A
Piston displacement 1372
Bore * Stroke 73*82
Compression ratio 9.5
Maximum output 70/ 6000
Maximum torque 115/ 3200
Maximum speed (Km/ h) 130
Emission Level China Ⅳ
Fuel tank (L) 37
Transmission
Type Synchromesh
Final gear Ratio 4.3
Steering Rack and Pinion
Suspension

Front: MacPherson strut and coil spring /

Rear: Leaf Spring

Brakes

Front: Ventilated Disc /

Rear: Drum, leading and trailing

Tyres 165/ 70R 13LT

Detailed Pictures

High Safety Big Capacity Mini Truck DLX-B03 1.5 Tons Capacity Gasoline Durable Truck

Company profile

CHONGQING BIG SCIENCE & TECHNOLOGY DEVELOPMENT CO., LIMITED, We are a well-known international auto manffacturer and oversea auto investment corporation in China. Our mission is to focus on overseas investment in automotive assembly plant chain projects.Our investments include capital and automotive manufacturing technology, brands, key equipment,kit car spare parts and credit support under guarantee conditions.We are a joint venture corporation control by China national automobile corporation and China financial capital investment corporation.The Chinese government has proposed "One Belt And One Road".Chinese carmakers are keen to "go global".While helping developing countries to achieve industrialization, we should also develop ourselves.http://chainautoassembly.com is also another official site of ours.

High Safety Big Capacity Mini Truck DLX-B03 1.5 Tons Capacity Gasoline Durable Truck

CORE COMPETITIVENESS OF CHONGQING BIG AUTO :
1. Formulate the joint venture cooperation mode suitable for overseas investment environment according to local conditions.

2. Customized provision of automobile production lines and production processes suitable for overseas productivity development level

3. Provide products suitable for overseas target markets according to target markets;

4. use our fifteen years of overseas investment experience to build a set of business models suitable for overseas developing countries.

5. Provide customers with after-sales service, technical education and management experience.
