900mm * 600mm * 550mm Suction Blast Cabinet Dust Free 550W Fan Power 250Kg Weight
900mm * 600mm * 550mm Suction Blast Cabinet Dust Free 550W Fan Power 250Kg Weight
900mm * 600mm * 550mm Suction Blast Cabinet Dust Free 550W Fan Power 250Kg Weight
900mm * 600mm * 550mm Suction Blast Cabinet Dust Free 550W Fan Power 250Kg Weight
900mm * 600mm * 550mm Suction Blast Cabinet Dust Free 550W Fan Power 250Kg Weight
900mm * 600mm * 550mm Suction Blast Cabinet Dust Free 550W Fan Power 250Kg Weight
Specifications
Brand Name :
TAISHENG
Model Number :
TS9060A
Certification :
ISO9001-2015
Place of Origin :
China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
T/T
Supply Ability :
30 sets per month
Delivery Time :
7 days
Packaging Details :
Pallet / Wooden + PE + ABF,
Material :
Carbon Steel
Working Chamber :
900mm*600mm*550mm
Air Consumption :
0.8-1.2m³/min
Fan :
550W
Dust Collector :
Bags
Separator :
Yes
Description

Small Type Dust Free Abrasive Blast Cabinets / Suction Sandblast Cabinet

Specifications

Working cabinet dimensions

900mm*600mm*550mm

Power Supply

220V 50Hz

Air pressure

0.3-0.7Mpa(kg/cm2)

Air consumption(Approx)

0.8~1.2m³/min

Quantity of process Gun

1pc

Load capacity

≤60Kg

Motor for dust collector

750W AC220V 50Hz

Machine lighting

15W AC220V 50Hz

Initial media charge(Approx)

5~10Kg

Weight of the machine(Approx)

250Kg

Abrasive recommended

Alumina oxide, Glass beads


900mm * 600mm * 550mm Suction Blast Cabinet Dust Free 550W Fan Power 250Kg Weight

Description:

Mainly used for cleaning the surface of the workpiece.

Its mainly made up of workpiece conveyor system, sand blasting cleaning booth, sand blasting dust removal devices, electrical control system.

Work principle: the workpiece through workpiece conveyor system into the sand blasting cleaning booth, in the blast clearing booth, it is used high-speed rotation of the blades will be acceleratory shot to the surface of workpiece.

It impacts and scrapes to remove rust and dirt on the workpiece surface, and then using high pressure air duct to clean dust balls and purge on the workpiece surface, so that it achieves to the purpose of cleaning the workpiece surface.

Applications:

Refurnishing sports part of car, motorcycle, electrical mechanical device, etc.
Eliminating fatigue stress and extending working life.
Enhancing the surface hardness of metal work piece and eliminating stress
Carving patterns/words and slip resistance treatment on the surface of metal and non-metal items

Competitive Advantage:

This type machine is suitable for precision workpiece’s surface treatment.
It can make use of fine sand materials to blast.
The sand materials can be recycled to use, and low sand materials consumption, little wear-tear of nozzle, low cost.
Good confined, no powder dust pollution.
The window is large and equipped with windshield wiper, making sure the clean visibility.
The simple operation, few breakdowns
Low noise
This machine is made of stainless steel, so it is durable.
It can add the rust inhibitor to the sand fluid, preventing iron workpiece rusting.
