Tea Powder Sachet Pouch Packing Machine 12ml Filling 40bags/Min
Tea Powder Sachet Pouch Packing Machine 12ml Filling 40bags/Min
Specifications
Brand Name :
LTPM China
Model Number :
LTDX
Certification :
CE, GMP
Place of Origin :
China
MOQ :
1set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
25sets/month
Delivery Time :
25days
Packaging Details :
Export standard wooden case
Bag size of inner bag :
L:50-60mm W:30-80mm
Item :
LTDX-115
Bag size of outer bag :
L:60-120MM W:70-90MM
Capacity :
20-40bags/min
Filling range :
2-12ml
power :
220V,50HZ,3.35KW
Weight :
700kg
Dimension :
1200*850*1900mm L*W*H
Description

product details

Operation interface

Large touch screen, simple operation, parameter setting, and clear display of machine performance.

Label fixed

Fully automatic structure, through the pneumatic drive system to put the thread and the label on the bag of the ancient ingot knife.

Cutting pliers

The precise rotating bee structure has an independent temperature system and can continuously carry out bag making and cutting.

Outer bag packaging

This machine uses a mechanical arm to put the inner bag into the outer bag without interruption, making the bag making more perfect.

Main performance and structural characteristics:

1. Double inverter control, the bag length is set and cut immediately, no need to adjust the idling, one step is in place, saving time and film.

2. Man-machine interface, convenient and quick parameter setting.

3. The fault self-diagnosis function, the fault display is clear at a glance.

4. High-sensitivity photoelectric eye color mark tracking, digital input of the sealing and cutting position, so that the sealing and cutting position is more accurate.

5. Independent PID control of temperature, better suitable for various packaging materials.

6. Positioned stop function, no sticking to the knife, no wasting of film.

7. The transmission system is simple, the work is more reliable, and the maintenance is more convenient.

8. All control is realized by software, which is convenient for function adjustment and technical upgrade, and never lags behind.

Tea Powder Sachet Pouch Packing Machine 12ml Filling 40bags/Min

Specifications:

Item LTDX-115
Bag size of inner bag L:50-60mm W:30-80mm
Bag size of outer bag L:60-120MM W:70-90MM
Capacity 20-40bags/min
Filling range 2-12ml
power 220V,50HZ,3.35KW
Weight 700kg
Dimension 1200*850*1900mm L*W*H
