Automatic Carton Corrugated Box Making Machine
Automatic Carton Corrugated Box Making Machine
Automatic Carton Corrugated Box Making Machine
Automatic Carton Corrugated Box Making Machine
Specifications
Brand Name :
LEADTOP
Model Number :
ZH-100
Certification :
CE certification
Place of Origin :
China
MOQ :
1 set
Price :
discuss personally
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25 days/month
Delivery Time :
25days
Packaging Details :
wooden box
Model :
ZH-100
Application :
bottle, Pharmacy
Power :
50hz
Dimension(L*W*H) :
1220*960*2100mm
Packing range :
80-250 90-170mm
Weight :
1500KG
Description

Automatic Carton Corrugated Box Making Machine

Feeding section

* Gluing and folding section

* Rectification and output section

* Gluing automatically by pneumatic control

* Rectification feeding part can move laterally with any size,makes the cartons formed well

* Cardboard conveyed and folded by flat belt , smooth and stable

* Lateral moving adjusted motorized control ,easy and smooth

* Shafts made of seamless steel pipe with thickness 20mm

* Paper fed by belt with high power vacuum suction control, making feeding easy and stable

* Rectification adjusted by eccentric bearings and stepless speed-djustment device, free of fish tail

* Automatic counting and stacking ,the cartons pushed out automatically when reach the setup number

* Pre-creasing and forming creasing wheels on the folding section makes the creasing line better,easy to be folded and free of

cracking

Applicability

* Second creasing makes the creasing line formed well

* The machine suitable for 3 ply and 5 ply cardboard gluing

* Paper feeding accurate under vacuum suction control

* Cardboard size:length 750mm-2400mm,width 300mm-1100mm

* Economic working speed:100-130m/min

* Core technology

* Stroke section makes the cartons formed well

* Output accurately and steadily

* Long service time

* Convey belts warranty:1 year

* Electric parts warranty: 1 year

* The main structure has lifetime warranty

* Carton joint glued well, meet standards, few waste.

* Double rectification structures are free of fish tail

* Accurate counting

* Carton forming quickly

Main Technical Parameter

Model

ZH-100

Weight in kg

1100

Steady production speed

50-100 cartons/min

Grammage

Between 60-70g/m2

Size range

(80-250) ×(90-170)mm (L×W)

Fold range

(1-4 )fold

Notice: The leaflet can be folded by the machine

Grammage

Between 250-350g/m2

Carton Size mm

(65-125)×(30-85)×(12-50)mm

Standard power supply

220V – 50Hz

Power consumption in KW

0.75

Air consumption

120-160L/min

Compressed Air Pressure

0.6MPa

Noise

<70 dB

Automatic Carton Corrugated Box Making Machine

Automatic Carton Corrugated Box Making MachineAutomatic Carton Corrugated Box Making Machine

Automatic Carton Corrugated Box Making MachineAutomatic Carton Corrugated Box Making Machine
