Chocolate Chewing Gum Automatic Counting Machine 10000pcs/Min
Chocolate Chewing Gum Automatic Counting Machine 10000pcs/Min
Chocolate Chewing Gum Automatic Counting Machine 10000pcs/Min
Chocolate Chewing Gum Automatic Counting Machine 10000pcs/Min
Specifications
Brand Name :
LTPM China
Model Number :
LTEC series
Certification :
CE, GMP, SGS, BV
Place of Origin :
China
MOQ :
1set
Price :
Negotiation
Payment Terms :
T/T,L/C,D/P
Supply Ability :
15sets/month
Delivery Time :
25days
Packaging Details :
Export Standard Wooden Case
Usage :
capsule,tablets,gums,rubber,etc.
Power :
220v 50hz single phase
Transmission :
Electronic
capacity :
200000pcs/h
Brand :
LeadTop
Line Length :
optional
Description

Products Description

1. Enhaced full line compatibility:controlled by micro-computer and anti-dust technology,this machine can be used for tablets(including irregular shape of tablets),capsules,soft capsules(including irregular shape of tablets,transparent or colorful gels),pellets and most other kinds of medicines and tabloids.

2. No blockage:Special designed hopper mouth,to prevent the drug blockage,even bottle with small mouth can be quickly filled.

3. No harm for materials:feeding and output are stable and averagrly,will do no harm on materials.Filling accuracy is guaranteed.

4. Detection function:machine will not count without detecting bottles' availability ,and will automatically reject abnormal filled bottles,and a certain degree broken of crushed tablets reject,self -diagnose,and alarm control system.

5. Anti-dust:Specially designed high anti-dust sensor technology,to ensure the machine running normally under heavy dust condition.

Good compatibility: tablets (including special-shaped tablets), capsules, soft capsules (transparent, opaque), pills and other solid preparations or solid particles can be counted and bottled.

Main features:

1. Three-stage vibrators:With 8-channel vibration, materials are distributed more evenly.

2. Reliable operation:It runs stably and smoothly with low noise.

3. High dust resistance:It adopts unique anti-dust photoelectric sensor.

4. Accurate counting:Due to photoelectric sensor detection and imported large PLC counting, bottle-filling error meets the international standard.

Main Technical Data
Model LTEC-12 LTEC-16 LTEC-24 LTEC-32
Slide wheel 12 Channels 16 Channels 24 Channels 32 Channels
Size of Object Tablet: φ5-12mm Capsule: 00#-5# all kinds of soft capsule
Size of bottles 20-300ml
The diameter for bottles mouth 20-80mm
Output 4,000pcs/min 6,000pcs/min 8,000pcs/min 10,000pcs/min
Capacity 40bottles/min 60bottles/min 80bottle/min 100bottles/min
Power 0.9KW 0.9KW 1.35KW 1.35KW
Power supply 220V 60HZ
Air pressure 6kgs/c
Overall dimensions(mm) 1700×1700×1900 2000×1700×1900 2800×1700×1900 3200×1700×1900
