Product Description:

The machines are primarily used for sheeting paper in various settings such as paper mills and printing houses. The process mainly includes the steps of Unwinding, Cutting, Conveying, and Collecting.

The machine is equipped with a Middle Slitting and Waste Edge Collecting System.

The slitting knife is adjustable and there is also an exhaust tube for waste edge on both sides.

The top slitter can be adjusted up or down, and the slitting width can also be manually adjusted.

The bottom slitter is fixed, but the slitting width can be adjusted manually as well.

The fan is powered by a motor.

The waste edge is collected using a Type-Y collecting pipe.

The machine is equipped with a high precision single rotary sheet cutter.

The cutting method used is advanced, resulting in decreased noise and load, and prolonging the life of the knife.

The tool apron is cast at one time, with features of stability.

The main driving roller has a grainy surface and is controlled by air pressure to ensure a tight grip on the paper web, resulting in smooth feeding and high speed operation.

Type: Tool Apron is fixed in the British style for increased efficiency.
Control Way: The squareness of paper is automatically adjusted based on the calibration on the Touching screen.

Type: Horizontal conveying is used with multi-stage capability for convenient counting and piling. High efficiency dust collecting equipment is also included.

To quickly separate cutting paper.

To convey paper in a tile-like shape at a slow speed. Control can be done individually or linked.

Technical Parameters:

Applications:

Customization:

Brand Name: CHM
Model Number: CHM-1400 II
Place of Origin: CHINA
Type of cutting: Top Blade Rotary, Bottom Blade Fixed
Total power: 29KW
Type: Roll Paper Sheet Cutter
Voltage: AC380V/220Vx50Hz
Requirement of the air pressure: 0.8MPa
Key words: Paper Roll Rotary Cutting Machine, Paper Processing Machinery, Roll To Sheet Paper Cutting Machine

Packing and Shipping:

Our Used Roll Paper Sheet Cutter Machine is carefully packaged to ensure safe delivery to our customers. We use high-quality materials and sturdy packaging methods to protect the machine during shipping.

• The machine is first wrapped in a layer of protective film to prevent scratches and damage during transportation.
• The crate is then sealed and labeled with the necessary shipping information.

We offer worldwide shipping for our Used Roll Paper Sheet Cutter Machine. The shipping method and cost will depend on the destination and the customer's preferences.

• For domestic shipping, we use reliable and trusted shipping companies to ensure timely and safe delivery.
• For international shipping, we work with reputable freight forwarders to handle customs clearance and delivery to the final destination.

Once the machine is shipped, we will provide the customer with tracking information so they can track the delivery status. We also provide insurance for the machine during shipping to give our customers peace of mind.
Our goal is to deliver our Used Roll Paper Sheet Cutter Machine to our customers in the best possible condition and in a timely manner. We strive to continuously improve our packaging and shipping methods to ensure a positive experience for our customers.

FAQ:

• Q: What is the brand name of this product?
  A: The brand name of this product is CHM.
• Q: What is the model number of this product?
  A: The model number of this product is CHM-1400 II.
• Q: Where is this product manufactured?
  A: This product is manufactured in China.
• Q: What is the maximum cutting width of this machine?
  A: The maximum cutting width of this machine is 1400mm.
• Q: What types of roll paper can be cut with this machine?
  A: This machine can cut various types of roll paper such as kraft paper, tissue paper, and thermal paper.
