Specifications
Brand Name :
JIGUO
Model Number :
MY-1500X
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
$100,000 to $800,000/1 Set
Payment Terms :
L/C, T/T
Supply Ability :
50 set
Delivery Time :
45 days
Packaging Details :
Wrap film or box
Weight :
22T
Warranty :
1 Year
After-sales service provided :
Engineers available to service machinery overseas,Video technical support,Field installation
Dimension(l*w*h) :
7600*5100*2260mm
Type :
Die-cutting Machine,Paper Cutting Machine
Computerized :
Yes
Power(w) :
25KW
Name :
Die cutting machine
Description

MY-1500X Bottom suction nozzle lead edge feeding

Automatic Die Cutting & Creasing Machine Manufacturer

Advantage

1. Which adopts high technology with gear main drive can run max speed 5500s/h, shorter

preparation process and perfect quality, which professional applies to all kinds of corrugated

board.

2. Paper hold down pressing plate is adjustable to adapt warped board, no double sheets

to ensure continuous and smooth feeding.
3. Front gauge non-stop back and forth adjustable to accommodate variation in gripper

margin.
4. Main drive adopts high quality precision worm gear and toggle system.
5. Centreline system for quick stripping tool set up and change over, compatiable with

centreline Il.
6. Front edge waste removal system removes and transfers waste edge outside the

machine visa conveyor belt.
7. Counter can set based on your products stack request, which will be improve working

efficiency.
8. Motorized upper frame suspending hoister.

Products Description​

PARAMETER
Model MY-1500X
Max. sheet size 1500X1105(mm)
Min. sheet size 500X465(mm)
Max. die cutting size 1480X1090(mm)
Max.cutting speed 5500s/h
Sheet Thickness ≤10mm
Max.pressure 400T
Total power 25kw
Net weight 22T
Overall dimension 7600X5100X2260mm
Air requirements 0.8Mpa,>0.36m³/min

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

Application

This automatic die-cutting machine can be equipped with a waste removal function, which

is suitable for Cigarette Boxes,Jigsaw Puzzle,Wine Boxes,Plastic Boxes,Hangtags,Paper

Boxes,Corrugated Boxes,Adhensive Stickers,etc.

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

Payment & Delivery

Our company has become an internationally famous enterprises with products sold well all

over the country and exported to over 20 countries, including the United States, South

Korea, Russia, India,Thailand, Brazil, Egypt, Greece, Poland, Italy, UK and so on.

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

Company Profile

Tangshan JIGUO Printing Machinery Co., LTD., founded in 1996, is a high-tech enterprise

started jointly by a number of senior engineers, and is located in the central area of YuTian

County within the golden triangle economic zone consisted by Beijing, Tianjin and Tangshan

city with 42.81 mu area covered. Our company has a technical team consisting of 160 elite

personnel who conteribute to our strong technical power, high level skills of design, assembly

and manufacturing, perfect management system and advanced processing and testing

equipment. Our company is specialized in production of post-print paper packaging equipment,

and has established long-term scientific cooperation for die-cutting machine schemes with the

Beijing Institute of Graphic Communication. The company is a modern enterprise incorporating

the design, research and development, sales and service.

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

Since first launched in market in 1996, with stable quality and reasonable price, our

products have received many praises for our quality and reputation. Our company has

become an internationally famous enterprises with products sold well all over the country

and exported to over 20 countries, including the United States, South Korea, Russia, India,

Thailand, Brazil, Egypt, Greece, Poland, Italy, UK and so on. JIGUO die-cutting series

products are the star products of our company. We have been incessantly pursuing our

dream; with excellent quality,preferential prices and excellent service, we have been

cooperating with friends at home and abroad closely to obtain mutual benefit and reciprocity,

and create a better tomorrow.

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

Our company adheres to the ideas "Technology boosts enterprise” and "Create first-class

products". Advanced management concepts and ideas regarding talents as the base,

technology as the soul,quality as the foundation, brand as the flag, marketing as the power

and service as the source of the company, contributes to rapid development of our enterprise.

Our products have passed the ISO9001 quality certification and the CE certification.Since its

establishment, Tangshan JIGUO printing machines have attended hundreds of large

exhibitions at domestic and abroad, and have won many honorary awards in the industry and

received thousands of praises from domestic and international packaging enterprises.

Attended all the big exhibition in domestic Beijing, Shanghai, Guangzhou. And all the big

exhibition in India, Egypt, Brazil, Turkey, Russia, Italy, Germany and so on. We have now

grown into a well-known domestic post-press equipment manufacturing expert.

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

Certifications

Our products have passed the ISO9001 quality certification and the CE certification.We have

now grown into a well-known domestic post-press equipment manufacturing expert.

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

Exhibition & Clients

Sheet 500mm Feeding Die Cutting Machine 5500s H Bottom Suction Nozzle Lead Edge

FAQ

1.Q:Are you trading company or manufacturer?

A: We are manufacturer, and also provide the business solution to all the friends.

2. Q:What is your delivery time ?

A:Normal delivery time is 30-55working days beside less stock model after received your deposit .

3. Q: Can you help us to buy other goods?

A: Sure of that, it is our honor to work for you, and control the goods quality.

4. Q:How was your machine warranty ?

A:our all machines has one and half year (18mouthes) guarantee. Beside guarantee we will supply

cost spare parts and free maintenance knowledge .

5. Q:How can you do after sales service ?

A:beside the quality guarantee, our company also regards the after sales service, using a full

arrange of service to solve the problems of clients. We supply multiple channels of service by 7x24
hours on phone / on site technical support / on site service / preventive maintenance also training
again.

6. Q:What’s your payment terms ?

A:30% deposit by TT , 70 % balance before shipping by TT or at sight L/C, western union /cash are also

accepted for us .
