Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination
Specifications
Brand Name :
STRPACK
Model Number :
Automatic Packing Machine
Certification :
CE
Place of Origin :
CHINA
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
50 SET/MONTH
Packaging Details :
Wooden
Filling range :
10-500g
Packing speed :
5-60 bags/min
Packing material :
OPP/CPP PET/PE etc.
Film roll width :
180 -420mm
Bag forming size :
(L) 80 -300mm (W) 80 -200mm
Film roll thickness :
0.05 -0.12mm
Description

Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-head Combination

Multifunctional Fully automatic High speed high quality potato chips biscuit granule packing machine

Technical Characteristics:

1. PLC control, man-machine interface, easy to operate and maintain.

2. Servo motor pulling film, optical tracking devices to keep accuracy and high speed.

3. Automatic multi head weigher and vertical packing combine in one unit (2 in 1 technology).

4. Separate circuit boxes for pneumatic control and power control. Noise is low, and the circuit is more stable.

5. Adjustment of bag deviation just needed to be controlled by the touch screen. Operation is very simple.

6. Close down type structure, defending inside mechanism from powder.

Technical Parameters:

Type GVF-420
Packing speed 5-60 bags/min
Display 10.4 inch touch screen/ 10.4
Weigher type 10/14 heads (10/14)
Weighing hopper volume 1.6L/2.5L
Weighing accuracy ±0.5-1.5g
Single weighing range 10-800g//20-1500g
Pillow bag size
Bag length 50-300mm(L)
Bag width 50-200mm(W)

Stand bag size
Bag length 50-300mm(L)
Bag front width 50-120mm(W)
Bag side width 40-80mm

The max. roll film width 420mm
Type of sealing Pillow bag, standing bag
Gas consumption 0.3m3/min
Air consumption 0.65mpa
Film pulling driven system Servo motor
Horizontal sealing driven system Cylinder / Servo motor
Power supply specification 220V 50Hz/60Hz 3.7Kw
Dead weight of machine 800KG
Whole machine cover material 304 stainless steel/304

Application:

It is suitable for all kinds of food, frozen food, coffee beans, oatmeal, granulated sugar, salt, rice, pet food, puff food, peanut, popcorn, cornmeal, dried fruit, seed, small hardware, etc.

Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination

Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination

Multifunctional Granule Packing Machine 10 - 500g Filling Range 180 - 420mm Film Roll Width With Multi-Head Combination

After-sales Service:
(1) Under stable voltage, the machines' quality that we sold will be guaranteed for 1 year
(2) Long time technology will be supplied.
(3) We can dispatch our engineer to your side for installing and debugging machines. Engineer's round-trip tickets, accommodation, and your side traveling fee will be charged by you. Engineer's salary will be USD60.00/day/person.
We can also supply training process for your engineers who come to china, so you can fit and debug machines by yourself.
