Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage
Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage
Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage
Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage
Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage
Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage
Specifications
Brand Name :
Huichen
Model Number :
Selective pallet rack
Certification :
ISO9001,SGS
Place of Origin :
Qingdao,China
MOQ :
1 x 40' container
Price :
USD 30-100 PER PALLET LOCATION
Payment Terms :
L/C, T/T
Supply Ability :
300 container per month
Delivery Time :
within 30 days after the deposit
Packaging Details :
Packed in Bundles with Pallets
Type :
Selective pallet rack
Material :
Q235,Q235 Q345 Steel
Upright :
Teardrop
Surface Treatment :
Powder Coating
Feature :
Corrosion Protection
Transport Package :
Packed in Bundles with Pallets
Color :
RAL coade
Description
Heavy Duty Steel Selective Pallet Rack for Industrial Warehouse Storage

Selective pallet racking is a material handling storage aid system designed to store materials on pallets (or “skids”).

Although there are many varieties of pallet racking, all types allow for the storage of palletized materials in horizontal rows with multiple levels. Forklift trucks are usually an integral part of any pallet rack system as they are usually required to place the loaded pallets onto the racks for storage. Since the Second World War, pallet racks have become an essential and ubiquitous element of most modern warehouses, manufacturing facilities, retail centers, and other storage and distribution facilities.

Selective pallet racking may be configured to store products at considerable heights. It is economical, durable, easy to install, and levels are easily adjustable for a temporary or permanent setting. Available in light, medium and heavy duty.

Heavy duty pallet rack shelf

Selective Pallet Rack, also called Heavy Duty Rack, is not only subject to storing various goods in small quantity, but storing uniform commodities in large quantity as well. It works with forklift or stacker.

Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage

Features

1. Taking use of cold-rolled steel uprights to improve the load capacity
2. Space between beams can be adjusted by 75mm pitch up and down
3. Assembled frame structure with safety facilities; easily assembled and disassembled; conveniently maintained and spare parts changed
4. Surface treated by epoxy powder coating with high corrosion resistance
5. It can be worked with pallet supports, back spacers; panels; upright protectors; frame guards and back mesh according to requirements.


Uprights (t=1.8/2.0/2.3/2.5/3.0mm)

Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage


Kaku Beams

Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage

Technical data for pallet rack system

Style Pallet storage warehouse rack
Selection Single Row, back-to-back Rows and multiple Rows


Dimension of pallet rack		 Standard Pallet:
1200*800(F)/1200*1000(F)/1100*1100(F)/1066(F)*1220

Depth: 1000MM/900MM/1020MM

Width: 2700MM/2300MM/2500MM/2432MM

Height: pitch is adjusted by increments of 75mm
Customized Pallet: other special size( you can contact us directly)
Beam Range Height: 80~160mm; Width: 45mm/50mm; Thickness: 1.5~2.5mm
Upright Range 80*60; 90*60; 90*70; 90*75; 100*67; 100*70; 100*75; 120*75; 120*87mm, Thickness: 1.5~3.0mm
Color Standard:
Customized: MOQ( per 20FT container)
(www.RALCOLOUR.com)
Weight Capacity 5000KG per level max ; 1500KG per pallet max
Package Full container: Nude Package; manual handling

Less than container: steel pallets + steel straps + corrugated paper
Lead time 15-20 days for one container

Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage

Heavy Duty Steel Selective Pallet Racking For Industrial Warehouse Storage
