Customized Semi Automatic 25 Kg Digital Filling Weighing Machine 100-300 Bags Per Hour ±0.2%@2δ Accuracy
Customized Semi Automatic 25 Kg Digital Filling Weighing Machine 100-300 Bags Per Hour ±0.2%@2δ Accuracy
Customized Semi Automatic 25 Kg Digital Filling Weighing Machine 100-300 Bags Per Hour ±0.2%@2δ Accuracy
Customized Semi Automatic 25 Kg Digital Filling Weighing Machine 100-300 Bags Per Hour ±0.2%@2δ Accuracy
Specifications
Brand Name :
Sanhe
Model Number :
DCS-25PV3
Certification :
ISO9001:2015, CE
Place of Origin :
Suzhou
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
T/T
Supply Ability :
30 Sets Per Month
Delivery Time :
Negotiable
Packaging Details :
Wood pallet , The pallet size is customized according to different products
Product Name :
25 Kg Digital Filling Weighing Machine
Suit for :
Particles / powders
Advantage :
Airflow feeding will not damage the shape of the material
Controls :
PLC
Packaging accuracy :
±0.2%@2δ
Packing speed :
100-300 Bags Per Hour
Power kw :
3 KW
For industry :
Chemical, petrochemical, fine chemical, pigment, dye...
Suit for bulk density :
between 0.15-1.5 T / m3
Features :
Semi automatic, high precision and less dust
Description
Customized Semi Automatic 25 Kg Digital Filling Weighing Machine 30-200 Bags Per Hour ±0.2%@2δ Accuracy
The Semi Automatic Weighing and Packing Machine supports the process of precise weighing and packaging of various products. The machine weighs the products in accurate measures and fill these in bags.

Changshu Sanhe Precision Technology Co., Ltd. (formerly Changshu Sanhe metering equipment factory),was built in 1998, with more than 100 stuff, China high tech enterpirse .

Changshu Sanhe Precision Technology Co., Ltd. is a scientific and technological enterprise specializing in the research, development, production and sales of particle and powder packing machine, liquid filling machine, batching system and automatic packing (filling) palletizing production line. Its products sell well at home and abroad and are widely used in chemical industry, petrochemical industry, fine chemical industry, chemical fertilizer Plastics, rubber, dyes, pigments, food, feed, non-ferrous metals, metal mines, non-metallic mines, building materials and other industries.
Scope of application of our of our 25 Kg Digital Filling Weighing Machine :
Suitable materials
Powder and thin granule......
Bag
Valve bag (automatic sealing bag)
Feeding type
Air flow
Alternative feeding type
Technical parameters
Automatic supply bag machine
1
Number of packing scale
1
Feeding mouth
1
One swing bag can with maximum feeding mouth number
1
Weighing range(Kg)
10-50
Packing speed(bag/H)
100-300
Packing Accuracy
Generally (+/- ) 0.2% Full Scale ( Note: special materials shall depend on the industrial standard )
Features & advantages :
1. Good service
2. Fast delivery
3. PLC technology of electronically automatic measurement , accurate measurement, dust free.
4. High capacity
5. Reliable and durable, long lifecycle of spare parts.
6. Firm, durable, easy to use
7. Suitable for powder, granule and clump.
8. Various of types/colors/size/specifications for selection
9. Hot sold by manufacturer/support OEM and ODM with good quality & price
10. Customer first, integrity highest

FAQ :
1. Are you a trading company or a factory?
---We are factory sell directly, and welcome to visit our factory in Changshu city,Suzhou,Jiangsu Province China.
2. Can you guarantee the quality of your valve bag packing machine?
---We have passed CE&ISO9001, and our packing machines have been sent to Eastern Europe, Middle East, Africa, South Asia, Southeast Asia, Oceania, America, etc.
3. How many years have you been manufacturing this machine?
---Since the foudation of our company, we have been manufacturing the machine, which updated many times, now the machine runs stable and of high quality.

Customized Semi Automatic 25 Kg Digital Filling Weighing Machine 100-300 Bags Per Hour ±0.2%@2δ Accuracy
Customized Semi Automatic 25 Kg Digital Filling Weighing Machine 100-300 Bags Per Hour ±0.2%@2δ Accuracy
The parameter and function table of the valve bag packer:

DCS-25PV1(1)

(exhausting type)

DCS-25PV1(2)

(screw type)

DCS-25PV1(3)

(airflow type)

DCS-25PV1(5)

(horizontal impeller)

DCS-25PV1(6)

(vertiacl impeller)

Scope of application

Suitable materials

Powder and ultrafine powder of good Air affinity

Powder and thin granule

Powder and thin granule

Powder and ultrafine powder

Powder and ultrafine powder

Suitable packing container

 Upper and lower spiral air supply single screw air flow Horizontal impeller Vertical impeller

Technical parameters

Weighing range(Kg)

 10-50 10-50 10-50 10-50 10-50

Packing speed(bag/H)

 30-180 30-120 30-200 30-250 30-250

Packing Accuracy

Generally (+/- )0.2%(Note: special materials shall depend on the industrial standard)

Control function

Automatic tare

 ○ ○ ○ ○ ○

Automatic quick and slow feeding

 ○ ○ ○ ○ ○

Automatic free fall compensation

 ○ ○ ○ ○ ○

Automatic minus deviation

 ▲ ▲ ▲ × ×

Automatic over weight alarms

 ○ ○ ○ ○ ○

Automatic self diagnosis failure

 ○ ○ ○ ○ ○

Manual/Automatic mode conversation

 ○ ○ ○ ○ ○

Communication port

 ▲ ▲ ▲ ▲ ▲

Regulatory function

Manual adjusting the height of bag

 ○ ○ ○ ○ ○

Suit for open and valve bag function

 ▲ ▲ ▲ ▲ ▲

Important auxiliary function

Blow bag function in advance

 ○ ▲ ○ ○ ○

Arch break function of hopper

 ○ ○ ○ ○ ○

Vibration at the bottom of the bag

 ○ ○ ○ ○ ○

Powder protection

Inflatable seal

 ▲ × ▲ × ×

Negative pressure dusting(not contain duster)

 ○ ○ ○ ○ ○

Automatic blow valve mouth

 ○ × ○ ▲ ▲

Safety protection

Electrostatic grounding

 ▲ ▲ ▲ ▲ ▲

ionic wind remove static

 ▲ ▲ ▲ ▲ ▲

Stop packing when lose power

 ○ ○ ○ ○ ○

Emergency stop

 ○ ○ ○ ○ ○

Ex-proof

 ▲ ▲ ▲ ▲ ▲

Mark: “○”is standard function；“▲”is choose function ；“×”is not has function

main features:

*valve bag packing for Powder and ultrafine powder.

*Can be twin-type packer

*Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.

Our hot sale products are:

Pellet Packing Machine

Automatic open mouth bag packing and palletizing line

Automatic valve bag packing and palletizing line

Automatic packing and palletizing line

Open mouth bag packing machine for granular

Open mouth bag packing machine for powder

Valve bag packing machine for granular

Valve bag packing machine for powder

Big bag packing machine

Big bag unloading station

Liquid filling machine

Various conveyors

It sales well in China and overseas market.
Sanhe--A wellknown packing and palletizing manufacture from China

95% of China Silica ( white carbon black ) factory use our packing machine.

main features:

*valve bag packing for Powder and ultrafine powder.

*Can be twin-type packer

*Can made into semi-packing and palletizing line with conveyors, sewing machine, heat sealer, fall bag conveyor, reshaping conveyor, weight checker, reject conveyor, pallet magazine, stacker.

Main sub-suppliers:

Name OF Outsourcing Sub-suppliers
Weighing Controller ZhiMei or JieMan
Load Cell Mettler Toledo / ZhongDianHangCe
PLC Mitsubishi
Touch panel Mitsubishi
Fold edge sewing machine Dechao
Pneumatic Equipment FESTO or SMC or airtac
Solenoid valve FESTO or SMC or airtac
Photoelectric switch Autonics
Metal detector METRON German
Robot FUJI EC-102
Motor WanNan
Sewing machine DeChao
Electric cabinet TongKe
General Electric Component SCHNEIDER

Utilities ( provided by buyer,for whole packing line )

1.Power(for every line) :

AC400V±10％；50Hz(three phase and five wires).

2.Compressed Air(for every line):

Pressure: 0.55~0.7 Mpa；

Consumption: 0.3N m3/min

Suction:8-10 mbar

Suction volume:1200 m3/hr.
