Hygienic Swing Tumbler Screening Machine High Precision
Hygienic Swing Tumbler Screening Machine High Precision
Hygienic Swing Tumbler Screening Machine High Precision
Hygienic Swing Tumbler Screening Machine High Precision
Hygienic Swing Tumbler Screening Machine High Precision
Hygienic Swing Tumbler Screening Machine High Precision
Hygienic Swing Tumbler Screening Machine High Precision
Hygienic Swing Tumbler Screening Machine High Precision
Specifications
Brand Name :
Sanhe
Model Number :
Tumbler screen machine
Certification :
ISO9001:2015, CE
Place of Origin :
Suzhou
MOQ :
1 Set
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
90 Sets Per Month
Delivery Time :
Negotiable
Packaging Details :
Wood pallet , The pallet size is customized according to different products
Product Name :
Tumbler screen machine
Usege :
Chemical, food, ceramics, power station, metallurgy, mining, building materials and other industries
brand :
Sanhe
Feature :
Easy-to-clean, hygienic design.
Advantage :
Energy and space-saving
Description

High Precision Swing Tumbler Screen Machine

Sanhe series tumbler screen machine is a kind of inertial equipment with mature technology and classical application. Its new design and unique structure make it the closest manual screen machine. The Tumbler sieve machine have bright application prospects for its perfect screening effect. From the aspect of its trajectory, it is a non-linear inertial vibrating screen.

Product Name DZYS Swing Sieve Tumbler Screen
Material stainless steel / carbon steel
Layer 1-5 layers
Voltage 240V/380V/414V/440V/460V…
Rotational speed 200 r/min
Diameter 600 mm – 2600 mm
Used industry Food industry,Chemical industry,Medicinal industry,Medicinal industry,Abrasive material and ceramic industry
PRODUCT STRUCTURE

Hygienic Swing Tumbler Screening Machine High Precision

TECHNICAL PARAMETER
Model Mesh zrea(㎡) Granularity(mm) Amplitude(mm) Power(kw)
DZYS-600 0.28

≤100

20-70

 0.75
DZYS-1000 0.66 1.5
DZYS-1200 0.98 2.2
DZYS-1500 1.67 3.0
DZYS-1800 2.37 4.0
DZYS-2000 2.89 4.0
DZYS-2600 5.3 5.5
APPLICATION
–Chemical industry:resin pigment,calcium carbonate,decorative coatings, medicine,etc
–Abrasive material and ceramic industry:building sand,alumina,silica sand,abrasive,refractory material,slurry, etc.
–Mechanical industry:casting sand,charcoal,grafito,powder metallurgy,
metal powder,etc
–Food industry:sugar,salt,alkali,flour powder,farina,gourmet powder,
starch,milk powder,yeast powder,etcHygienic Swing Tumbler Screening Machine High Precision

DETAILS IMAGES

Hygienic Swing Tumbler Screening Machine High Precision

CUSTOMIZED SERVICE
According to the needs of the buyer, the number of swing screen layers can be customized. At present, our factory supports the customization of one to four layer swing screen.
Stainless steel material is the first choice for medical grade and food grade buyers, carbon steel is the first choice for cost saving, contact with stainless steel can not only meet the health requirements, but also save costs.

Hygienic Swing Tumbler Screening Machine High Precision

CUSTOMER SITE

Hygienic Swing Tumbler Screening Machine High Precision

Hygienic Swing Tumbler Screening Machine High Precision

PACKING & DELIVERY

Hygienic Swing Tumbler Screening Machine High Precision
