Specifications
Brand Name :
JINYATE
Model Number :
PM-150
Certification :
CE SGS
Place of Origin :
China(mainland)
MOQ :
1 set
Price :
Negotiable
Supply Ability :
99 sets per year
Delivery Time :
35 working days
Packaging Details :
standard wooden cases
product name :
sleeve lable machine
suitable label :
PVC ,PET ,OPS
bottle diameter :
φ25mm –φ125mm
Speed :
100/min
dimension :
1000*860*1800L*W*H(mm)
material :
SUS304
Description

Electric Driven Automatic Bottle PVC Lable Sleeve Machinery /

Equipment

Product Introduction

All-cover type stainless steel host machine: the whole machine is waterproof as well as rustless.

Adjustable cutter head: uniquely cyclotron cut-off, double sided cutting edge with a long service life.


Single positioning centre guide pillar: a more stable for label delivery.


Synchronous bottle divider: a more stable transmission for bottle.


Bottom set of label brush:a more precision for casting label.


Label-controlling electric-eye shelf:unique combination of tail and electric-eye to improve the precision for

cutting off The membrane materials.


Push-button control cabinet: a more humanized operation.


Independent feeding material shelf: the position of the material shelf is optional at will.


Electrical Appliance Configuration Specification:


It adopts PLC programmable controller,imported servo motor,servo driver,frequency converter and

transducer; besides,it dopts The positioning module to ensure the casting label precise, rapid and stable.


Applicable Bottle Types:


Various kinds of bottle types, for example: round bottle, square bottle, flat bottle, curved bottle and cup-

shaped, etc.

Technical parameter

Techniacal Parameter
No Item Technical data Unit Symbols
1 Import Power 3.0KW KW
2 Import Voltage ∮3, 380/220 VAC
3 Capacity(production speed) 150 bottles per min
4 Dimension of Host Machine (mm) L2100 × W850 × H2000 mm
5 Applicable Diameter Container (mm) φ28 ~ φ120 mm
6 Applicable Label Length (mm) 30~250 mm
7 Applicable Thickness Label (mm) 0.03~0.13 mm
8 Applicable Inner Diameter of Paper Tube 5''~10''

product pictures

Electric Driven End Of Line Packaging Equipment 150B/Min PVC Lable Sleeve Machinery

Electric Driven End Of Line Packaging Equipment 150B/Min PVC Lable Sleeve Machinery

Electric Driven End Of Line Packaging Equipment 150B/Min PVC Lable Sleeve Machinery
