Specifications
Brand Name :
JYT
Model Number :
QHS
Certification :
CE SGS
Place of Origin :
China(mainland)
MOQ :
1 set
Price :
Negotiable
Supply Ability :
99 sets per year
Delivery Time :
35 working days
Packaging Details :
standard wooden cases
product name :
CO2 mixer
usage :
beverage mixing
mixing rage :
1:3-1:6
working pressure :
0.05-0.08
capacity :
2T-10T/H
Material :
SUS304
Description

QHS-2000 Carbon Dioxide Mixer, Carbonation Machine / Soft

Drinks Mixer

product description

industrial CO2 beverage mixer , which were developed pn the base of advanced similar

technologles abord, are mainly appliciable for mixing water-syrup-CO2 proportionally in beverage

industry. industrial CO2 beverage mixer is the most advanced Beverage Mixer in this field at

present.

There is a set of advanced water-gas mixing device on the machine. This industrial CO2

beverage mixer could proportionally mix syrup, additive, drink water and CO2 into finished

beverage before bottling. The iindustrial CO2 beverage mixer also could thin beer or aerate beer

or produce sparking wine before bottling.

technical parameter

Model QHS-1500A QHS-3500A QHS-3000 QHS-5000 QHS-7000 QHS-10000 QHS-15000
Capacity(L/hr.) 1000-1500 2000-3500 2000-3000 4000-6000 8000-9000 10000-12000 12000-16000
Gas content in beverage(GV) 1.5-2.5 1.5-2.5 >3.0 >3.0 >3.5 >3.5 >3.5
Mixing range(Syrup-water) 1:3-1:6 1:3-1:6
Tempeature in chilled water 0-5ºC 0-4ºC
Water deoxidization method Deoxidized by CO2 Deoxidized by vacuum system
Working pressure of pre-carbination tank and syrup tank(Mpa) 0.05-0.08 Pre-carbonation tank:-0.08~-0.06
Syrup tank:0.05~0.08
Working pressure in storage tank(Mpa) 0.2-0.5 0.2-0.5
Power supply(kw) 1.1 1.5 3.70 5.2 8.5 11 15
Overall dimension(mm) 900*700*2000 1100*900*2100 1600*1200*2100 2000*1500*2200 3200*2100*2500 3800*2200*2750 4300*2200*2550
Weight(kg) 500 650 1200 1800 2800 4800 6500

Products Structure and Working Procedur

(1). CO2 tank, syrup tank, liquid level device, static mixing device, tank, electrical controlling

system, air providing tank, and necessary producing pipe and cleaning pipe including ball valve,

magnetism valve, check valve are composed this machine. (See photo 1: main structure)

(2). Main working Procedure

a. Cooling water→multi-grade pump→oxygenating CO2→volume control

b. Cooling syrup→multi-grade pump→syrup tank→volume control

(a and b → multi-grade pump→static mixing device→

c. CO2 air resource→filter and pressure reducing→ tank→filling machine

product pictures

QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage

QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage

QHS-2000 Automatic Drink Machine 1:3 - 1:6 Mixing Rage For Mixing Beverage
