Tomato Paste Can Filling And Sealing Machine Pneumatic Driven 1 Year Warranty
Tomato Paste Can Filling And Sealing Machine Pneumatic Driven 1 Year Warranty
Specifications
Brand Name :
Jinyate
Model Number :
YGF12-1
Certification :
CE,ISO,SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 Set/Sets
Price :
Negotiable
Supply Ability :
15 Set/Sets per Month
Delivery Time :
30-45 working days
Packaging Details :
PE film wrapping,Standard wooden boxes packaging
Capacity :
2000CPH
Filling material :
vegetable paste,peanut paste, sauce,oil
Function :
Filling ,sealing
Weight :
2000kg
Overall dimensions (LxWxH) :
1900x1800x2200mm
Condition :
New
Driven Type :
Electric+pneumatic
Warranty :
1 year for free
Description

Tomato / Shrimp Paste Can Filling And Sealing Machine Piston

Volumetric Filling

Specifations

Tomato / Shrimp Paste Can Filling And Sealing Machine Piston Volumetric Filling

1. Tomato paste filling and sealing machine

2. 2-in-1 unit
3. Piston Volumetric Filling,Rotary type
4. can sealing machine

Features

1. This 2-in-1 unit machine is suitable for filling paste or oil product, such as ketchup, jam, fruit

and vegetable paste, cooking oil, honey, corn soup, peanut paste, sauce. It also can be used for

pulp, edible bird's nest, aloe, rice wine and so on.

2. It can be used for fixed amount small package filling,straight line type

filling,mechamcal,electric,apparatus control of all sorts of viscous and nonviscous,erosive liquid,such as

plant oil chemlcal,liquid,daily chemical industry.

3. It is rather simple and rapid to change items,the design is quite distinct,the property is Very

advantageous,its appearance corresponds to international concept for mechanlcal equlpment.

4. It has applied SIEMENS PLC computerlzed control,from germany. It has intellectual,protection function.

5. It works stably, fills precisely, and suits for cold and hot filling. The piston and piston barrel after the

treatment of top technology cooperate accurately, durable and wearable.

6. It is equipped with material stirring system, three point liquid level control, frequency conversion

adjustment, bottle in and out protection, automatic speed adjustment, filling with bottle and no filling

without bottles.

7. It adopts good stainless steel material, which meet the requirement of food sanitation.

8. Vacuum pump can make sure there is no dripping oil on bottle body or machine surface, keep the

bottle and machine clean.

Technical parameter

Model YGF12-1
Can 2000CPH
Filling heads 12
Sealing heads 1
Filling time 5 second(approx)(100ml/min)
Filling temperature 18-20℃
Filling tank Semi closed type filling tank, using worm gear to adjust the height
Filling valve Using cam to force down
Speed control AC MOTOR+REDUCER+INVERTER
Gas consumption 100NL/min(5-6Kg/cm²)(take 100EA as the base)
Power 2.2Kw
Weight 2000 Kg

Overall dimensions

(LxWxH)mm

 1900x1800x2200

Electric control cabinet

Tomato Paste Can Filling And Sealing Machine Pneumatic Driven 1 Year Warranty

Touch screen

Tomato Paste Can Filling And Sealing Machine Pneumatic Driven 1 Year Warranty
