PET Bottle Mineral Water Filling Machine , Water Bottling Equipment
PET Bottle Mineral Water Filling Machine , Water Bottling Equipment
PET Bottle Mineral Water Filling Machine , Water Bottling Equipment
PET Bottle Mineral Water Filling Machine , Water Bottling Equipment
PET Bottle Mineral Water Filling Machine , Water Bottling Equipment
PET Bottle Mineral Water Filling Machine , Water Bottling Equipment
Specifications
Brand Name :
JINYATE
Model Number :
CGF16-12-6
Certification :
ISO CE
Place of Origin :
China, mainland
MOQ :
1 set
Price :
pls inquiry
Supply Ability :
99 sets per year
Delivery Time :
35 working days
Product name :
water bottle filling machine
Function :
rinsing filling capping
model type :
tri-monobloc
suitable bottle :
PET plastic bottle
Filling material :
water, juice, tea, still drink
capacity :
4000BPH(500ml)
material :
SUS304
Control :
PLC+Touch screen
Description

PET Bottle Mineral Water Filling Machine Price,

Water Bottling Equipment

Machine description

This machine is a tri-monobloc, it integrates rinser filler and capper in

one monobloc, suitable for PET bottled water, juice, tea or other still

drink. It's rough capacity is 4000BPH(500ml), 2500BPH(1000ml),

2000BPH(2000ml).

Besides this filling machine, we can supply all complete line plants:

water treatment system; filling system; end-line package system

Technical parameter

Model CGF16-12-6
Capacity 4000bph (500ml PET bottle)
Bottle Height 150-320mm
Bottle Diameter 40-108mm
Filling Tenperature ambient
Filling Technology gravity filling
Applications purified water,mineral water, juice, still drink
Power supply 380V 50Hz 3Phases or customized
Total power 4.23KW
Dimension 2150*1500*2300mm
Weight 3000kg

Machine pictures

Overall look

PET Bottle Mineral Water Filling Machine , Water Bottling Equipment

internal look

PET Bottle Mineral Water Filling Machine , Water Bottling Equipment

rinser station

PET Bottle Mineral Water Filling Machine , Water Bottling Equipment

Character

  • For different bottle size ,just need to change column wheel and turn table disc .
  • All the part which contact with filling material is high quality stainless steel ,without dead angle ,easy to clean .
  • Use high speed filling valve ,the liquid-level position control accurately ,to ensure that meet the requirements of filling process .
  • Capping head use magnetic constant torque device , make sure capping with high quality and without caps damage .
  • High-efficiency caps ordering system has prefect automatic control and protection devices .
  • Carried with prefect protection system to overload ,it can be used to protect facilities and operators efficiently .

If you want to get precise quotation, pls leave your capacity here,

more details i know more exact the proposal is... ...
