Specifications
Brand Name :
JYT
Model Number :
QHS
Certification :
CE SGS
Place of Origin :
China(mainland)
MOQ :
1 set
Price :
Negotiable
Supply Ability :
99 sets per year
Delivery Time :
35 working days
Packaging Details :
standard wooden cases
product name :
CO2 mixer
usage :
beverage mixing
mixing rage :
1:3-1:6
working pressure :
0.05-0.08
material :
SUS304
Voltage :
380V 50hz 3phases
Description

QHS CO2 Mixer, Drink Mixer For Carbonate Beverage / Soft Drink/

Energy Drink

product description

Beverage Co2 / Carbonated Drink Mixer (carbonated drinks mixer)is used for producing all
carbonated beverages (water, syrup, and CO2 mixing), for example lemon, coca cola, fruits juice
and so on. It is the main equipment in whole beverage production line. (Especially for middle and
higher standard beverage production).

Products Structure and Working Procedur

(1). CO2 tank, syrup tank, liquid level device, static mixing device, tank, electrical controlling

system, air providing tank, and necessary producing pipe and cleaning pipe including ball valve,

magnetism valve, check valve are composed this machine. (See photo 1: main structure)

(2). Main working Procedure

a. Cooling water→multi-grade pump→oxygenating CO2→volume control

b. Cooling syrup→multi-grade pump→syrup tank→volume control

(a and b → multi-grade pump→static mixing device→

c. CO2 air resource→filter and pressure reducing→ tank→filling machine

technical parameter

MODEL QHS-1500 QHS-3000 QHS-6000 QHS-8000 QHS-10000
Production capacity (KG/H) 1500 1500-3000 4000-6000 6000-8000 8000-10000
Regulation range of sugar&water mxing ratio 1:3-1:10
Gas content (CO2:H2O volume ratio) 2.5 3
Mixing accuracy ≤2%
Chilled water entrance temperature 0～5℃ 0～4℃
Chilled water entrance pressure 0.01～0.08MPa
Syrup entrance temperature 2～8℃
Syrup entrance pressure 0.01～0.08MPa
Carbon Dioxide purity >99.9%
Syrup tank working pressure 0.01～0.09MPa
Storage tank working pressure 0.2～0.5MPa
Motor total power (KW) 1.1 3.5 5.1 8.5 11
Dimension(mm) 1030*1180*1930 1650*1300*2000 1900*1300*2250 3200*2100*2500 3800*2200*2750
Weight(KG) 600 1300 2000 2800 4800

product pictures

High Strength SUS304 Automatic Drink Mixing Machine For Soft / Energy Drink

High Strength SUS304 Automatic Drink Mixing Machine For Soft / Energy Drink

High Strength SUS304 Automatic Drink Mixing Machine For Soft / Energy Drink

if have a furthur learn, we will provide you more helpful information...
