2 In 1 Glass Bottle Automatic Milk Filling Machine 6.68KW For Aseptic Sealing
2 In 1 Glass Bottle Automatic Milk Filling Machine 6.68KW For Aseptic Sealing
Specifications
Brand Name :
Jinyate
Model Number :
RCGF18-6
Certification :
CE,ISO,SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1 Set/Sets
Price :
Negotiable
Payment Terms :
L/C, T/T
Supply Ability :
15 Set/Sets per Month
Delivery Time :
30-45 working days
Packaging Details :
Good plastic film wrapping,Standard wooden Boxes
Bottle type :
Glass bottle
Overall dimension(L*W*H) :
2000*1800*2200mm
Capacity :
6000BPH(500ml)
Filling temperature :
Room temperature
Control system :
PLC control+touch screen
Automatic Grade :
Fully-automatic
Function :
Bottle filling capping
Material :
SS304/316
Description

2-In-1 Glass Bottle Purified Milk / Juice Aseptic Filling And Sealing

Machine

Specification:

1. 2-in-1 glass bottle filling machine

2. Aseptic milk filling and sealing machine

3. Capacity:6000 bottles per hour

Features:

1. It Is used in hot filling and sealing of milk,green tea, black tea, and fruit juice. The machine integrates

filling, capping together. The design is scientific and reasonable. With the advantages of scientific and

reasonable design, beautiful appearance, convenient operation and maintenance, and high degree of

automation, it is the first choice for hot-filling drink.

2. It is designed bottleneck suspension type and applies the lift technology of filling valve, which meets the

need of hot filling technology below 95°C. It adopts human-machine touch screen control, PLC

computerized control, transducer control and other advanced technology.

3. All the parts of 2 in1 juice filling machine contacting with material are made from SUS304 stainless

steel. The primary electric components and pneumatic components introduce international famous

products, such as Mitsubishi, Schneider, Omron and so on.

4. The design of filling structure is reasonable and hygiene dead angle, the run of equipment is stable, it

can control the material from the bottleneck, the control accuracy is within ±2mm.

5. The filling valve material is SUS304

6. The filling system has liquid level automatic control.

7. Filling valve lift is controlled by the valve elevator, after filling valve contact the bottleneck ,it start to fill.

8. Bottle is conveying by the wheel in the filling part.

9. The juice or other hot beverage can be backflow by return tank to control filling temperature.


Technique parameter

Model RGF18-6
Productivity 6000BPH
Filling Head 18
Capping Head 6
Bottle Volume 350ml~2000ml±10ml
Bottle Diameter φ50-92mm
Bottle Height 150-310 mm
Filling Tolerance ±2%
Cap Size 28mm and 30mm PE Standard Caps
Air Pressure 0.6MPa
Air Consumption 500 L/min
Filling Water Consumption 3 m3/h
Rinsing Water Consumption 1 m3/h
Motor Power 6.68kW
Voltage 380V
Dimension (L×W×H) 2450*1800*2200mm
Weight 3000kg
Filling Principle Gravity Filling


Touch screen

2 In 1 Glass Bottle Automatic Milk Filling Machine 6.68KW For Aseptic Sealing

Electric control cabinet

2 In 1 Glass Bottle Automatic Milk Filling Machine 6.68KW For Aseptic Sealing

Customized service

1. We can design the machines according your requirements (materil ,power,filling type,bottles, and so

on),at the same time we will give you our professional suggestion,as you know,we have been in this

industry for many years.

2. We offer free technical support and consultation,such as draw the factory layout for you, alalyze the

source water report and so on.

After-sales service

1. We will delivery the machine and provide the bill of load on time to make sure you can get the machine

quickly.

2. When you finish the Preparation conditions ,our fast and professional after service engineer teamwill go

to your factory to install the machine,give you the operating manual ,and train your employee until they

can operate the machine well.

3. We provide one year warranty with spare parts free.

4. We ask the feedback from our customer and offer some help when the machine have been used for

some time.
