Cosmetic Spray Aerosol Bottle Filling Capping And Labeling Machine For Round Aluminum Can
Cosmetic Spray Aerosol Bottle Filling Capping And Labeling Machine For Round Aluminum Can
Cosmetic Spray Aerosol Bottle Filling Capping And Labeling Machine For Round Aluminum Can
Cosmetic Spray Aerosol Bottle Filling Capping And Labeling Machine For Round Aluminum Can
Specifications
Brand Name :
Higee
Model Number :
HG-SF200
Certification :
CE
Place of Origin :
SHANGHAI-CHINA
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
30 sets per month
Delivery Time :
30 working day
Packaging Details :
Wooden case
Model :
HG-SF-200
Maximum Air Consumption :
2/min
Speed range :
2400-3600 cans/hr (40-60cans/min)
Applicable Aerosol Can Diameter :
35-65mm
Applicable Aerosol Can Height :
80-330mm
Warranty :
18 month
Filling Precision :
≤ ±m(liquid level error)
Cetificatiom :
CE
Description

Cosmetic automatic spray can aerosol filling machine round can cup

capping packing machine with MITSUBISHI PLC

Feature:

Spray Bottle filling capping and labeling machine

1. can arrange machine

2. Automatic gas filling & sealing machine

3. Automatic liquid Filling machine

4. Automatic Auto pressing machine

5. Automatic weighing machine

6. Ink printing

7. Conveyor, ex-motor and packing table

Specification:

filling volume 50-750ml
Filling accuracy ≤±1%
Inflation Accuracy ≤±1%
Production Capacity/filling speed 2400-3600 cans/hr (40-60cans/min)
Required labor per shift 4-5workers
Working Pressure 0.6-0.8Mpa
Maximum Air Consumption 2/min
Applicable Aerosol Can Diameter 35-65mm
Applicable Aerosol Can Height 80-330mm

Configuration:


Electronic control system part
The electronic components like PLC and transducer are from Mitsubishi, Siemens, Omron, etc., The pneumatic devices are also from international famous brand.
Main electric brand
Touch screen: Weinview or Siemens
PLC program controller: Mitsubishi or Siemens
Inverter: Mitsubishi or Siemens
Photoelectrical controller: Omron or Autonics
Proximity switch: Omron
Other electrical components: Schneider
Pneumatic component: Airtac or SMC or Festo
Water pump: CNP or Grundfos
Main motor: SL or ABB or SEW
Bearing: Harbin or Igus

Main parts:

Cosmetic Spray Aerosol Bottle Filling Capping And Labeling Machine For Round Aluminum Can

Feeding parts

Worker putting bottles on the Bottles feeding table,

then the table will feed the bottles to the conveyor belt.

Filling parts:

Tt‘s’ provided with a sealing head, 2 gas filling heads, 2 booster pumps, as well a gas storage tank with an energy accumulator; It has the feature that guiding devices are provided at both sealing head and inflating heads. Reliable sealing quality, little leakage of gas inflating. Advise: build a filling room, to enhance security

 Cosmetic Spray Aerosol Bottle Filling Capping And Labeling Machine For Round Aluminum Can
Cosmetic Spray Aerosol Bottle Filling Capping And Labeling Machine For Round Aluminum Can

Inserting and capping

Automatic cap sorting, feeding and capping system for different sizes caps.

This parts can be make according to client's caps' shapes. and it can be 1/2/3... heads capping.

Labeling parts

It is for stick label.
Automatic labeling round bottles, square bottles or other types of bottles. It can be one side labeling, two side labeling and so one.
 Cosmetic Spray Aerosol Bottle Filling Capping And Labeling Machine For Round Aluminum Can

Service:

1. System control: The main machines including the liquid filler and the sealing and gas filling are completely pneumatic controlled.

2. Safety guarantee: Ex motors are applied for cans arranging machine and the feeding conveyor; the power supply cable is going through PVC pipes and anti-explosion junction boxes, connected by anti-explosion switch; the casing is earthed to prevent electrostatic; both liquid filler and inflating machine are protected by cabinet (stainless steel frame with 4mm annealed glass) to prevent injury due to cans blasting. Advise: built the filling room specifically for the gas charging machine, to enhance security and reduce the risk of explosion.

3. Service Guarantee:

Providing easy-broken parts and accessory free of charge within one year, if need engineer for installation, test and training, the buyer should pay all the cost, and should buy local life insurance for our engineers and pay them USD100/day.
