Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
Specifications
Place of Origin :
Shanghai, China (Mainland)
Brand Name :
JB
Certification :
CE
Price :
US $7,400-7,600 / Sets | 1 Set/Sets Tea bag packing machine (Min. Order)
MOQ :
1 Set/Sets
Model Number :
JB-180C
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
50 SET PER MONTH
Delivery Time :
20 WORKING DAYS
Packaging Details :
WOODEN BOX
Type :
Multi-Function Packaging Machine
Function :
Embossing, Filling, Sealing, Slitting, Wrapping
Application :
Chemical, Food, Medical, Double chamber tea bag with knot ties
Packaging Type :
Bags, Film, Foil, Pouch, Tea granules filling packing machine
Packaging Material :
Plastic, Wood, Tea granules filling packing machine
Automatic Grade :
Automatic
Driven Type :
Electric
Voltage :
220V
Power :
3.7KW
Dimension(L*W*H) :
1200*900*1900
After-sales Service Provided :
Overseas service center available
name :
Double chamber tea bag with knot ties
packing speed :
30-60bags/min
packing range :
1-15g (depends on product)
inner bag size :
L 50-70mm, W 40-80mm
outer bag size :
L 70-120mm, W 60-90mm
tag :
L 20-24mm, W 40-55mm
controller :
PLC
metarial :
stainless steel 304
packig type :
thread with tag
warranty :
1 year
Description

JB-180C Tea Bag Packing Machine Full Automatic Filter Paper Small Sachets Tea Bag Pouch Packing Machine With Envelop

JB-180C Tea granules filling packing machine, with filter inner packing , outer packing, thread and label, filling weight 1-15g/pack., heat sealing.

Tea bag packing machine Full automatic filter paper small sachets tea bag pouch packing machine with envelop

Used for packing tea, Chinese herbs, coffee, etc.

1. PLC control system, color touch screen display, cup volumetric filler/electronic weighter measurement, this machine is the latest type of multi-function tea bag packaging machine.

2. The main features of this machine are: one-time complete inner and outer bag packing, avoid direct contact with the material by hand.

3. Inner bag is made by filter paper, which can be automatically packed with thread and label. Outer bag is made from compound film.

4. Machine body and product touching part are made by 304 stainless steel.

Model

JB-180C

Sealing type

3/4 sides seal

Packing weight

3-15g (depends on product)

Inner bag size

Width 40-80mm , length 50-70mm

Outer bag size

Width 60-90mm, length 70-120mm

Outer bag film width

≤ 180mm

Production capacity

30-60 bags/min

Tag size

Width 40-55mm, length 20-24mm

Thread length

155mm

Power supply

AC220V, 50/60Hz

Power

3.7 KW

Overall dimension

L1200 × W900 × H1900mm

Net weight

500kg

Check out our Other tea bag packing machine ,coffee pod packing machine, pyrimad nylon triangle tea

Bag Packing Machine :

1)YB-180C Tea granules filling packing machine, with filter inner packing , outer packing, thread and label, filling weight 1-15g/pack., heat sealing.

Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler

Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
Full Automatic Tea Bag Packing Machine With PLC Control System / Cup Volumetric Filler
