Stainless Steel Automatic Metal Polishing Machine For Tank Top Head / Cone
Stainless Steel Automatic Metal Polishing Machine For Tank Top Head / Cone
Stainless Steel Automatic Metal Polishing Machine For Tank Top Head / Cone
Stainless Steel Automatic Metal Polishing Machine For Tank Top Head / Cone
Stainless Steel Automatic Metal Polishing Machine For Tank Top Head / Cone
Stainless Steel Automatic Metal Polishing Machine For Tank Top Head / Cone
Specifications
Place of Origin :
HeFei,China
Brand Name :
ZTPolish
Model Number :
ZTD
Price :
US $1,000-10,000 / Sets | 1 Set/Sets (Min. Order)
MOQ :
1 Set
Certification :
CE.ISO9001.ISO14001
Supply Ability :
20Sets per month
Packaging Details :
Plywood case
Name :
Metal automatic seal head polishing machine
Rotary motor power :
0.75kw
Temperature :
-10--40℃
Relative humidity :
<90%
Weight :
1500kg
Materials :
stainless steel
Delivery time :
20-45days
Speed :
2300r/min
Description

Metal polishing machine Automatic control for Tank top head and cone

Detials of polishing machine

Specifications of Metal automatic seal head polishing machine :

A), Polishing machine is used for polishing and buffing the stainless steel seal head, ellipsoidal head ,Butterfly head.

B), It is also called abrasive finishing machine,buffing machine, Application of the polish machine :stainless steel tank,vessel , seal head ,ellipsoidal head ,Butterfly head inside or outside from 20-1200 mesh ,with mirror polished .

C), Specification of the polish machine :

D), Diameter:1000 - 8000 mm

Feature of Metal automatic seal head polishing machine :

1. Using cloth emery disc , low cost and high efficient ,mirror polished .

2. Frequency speed control ,high quality .

3. Roughness as 0.1 um.

4. Speed : 8 m2/hour

All parameter listed in this table is only to supply reference,all dimensions is based on real solids.

Metal automatic seal head polishing machine advantages:

1, Easy-handing and safety.

2, Advantage design.

3, Almost full automatic control.

4, Equality heat and good heat distribution.

5, Durable and reliable.

Main specification

Product name Dished head polishing machine
Model ZT-701
Final finish requirement Mirror finish;hairline;matt
Processing diameter range 500-3000mm
Grinding head motor power 4KW;5.5KW
Draving motor power 0.37KW;0.75KW
Workpiece rotation 0.75-3KW
The length of abrasive belts 1880*50mm
Applicable abrasive materials belts,flap wheel,flax wheel,cloth wheel
Buffing wheel size 300*50*32mm
Power supply voltage AC three-phase 380V
Air Supply 0.2-0.6MP
Application Dished head,tank top.cone outside and inside polish
Model ZT-701
Size 3000*3600*1500mm

Stainless Steel Automatic Metal Polishing Machine For Tank Top Head / Cone

Main products

Tank polishing machine

Dished head polishing machine

Dual-use tank and seal head polishing machine

Plane polishing machine

Kitchenware polishing machine

Bent pipe polishing machine

Square pipe polishing machine

Round pipe polishing machine

Sand belts polishing machine'

Self-automatic polishing machine

FAQ

Q: Are u factory?

A: We have been the manufacturer of metal polishing machine for 7 years.

Q: What's your feature?

A: We study in producing the metal polishing machine always and only.

Q:What's your advantages?

A:We are at the top level in metal polishing machine area and have price and technology advantages. And we are the second factory in China mainland who begin to manufacture the metal polishing machine.
