Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal
Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal
Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal
Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal
Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal
Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal
Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal
Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal
Specifications
Place of Origin :
HeFei,China
Brand Name :
ZTPolish
Model Number :
ZTD
Price :
1 Set/Sets (Min. Order)
MOQ :
1 Set/Sets
Certification :
CE.ISO9001.ISO14001
Product Name :
Stainless Steel Mirror Polishing Machine
Voltage :
380V
Color :
As your request
Spindle speed :
0-2800r/min
Work efficiency :
0.5-2m/min
Size :
4000x3200x1800mm
Description

Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal

1. Processing objects and requirements:

1.1 Purpose: The equipment is mainly used for grinding and polishing oxide layer for metal sheet

2.2 The workpiece range requirements:

Items Dimension
Sheet width <1500mm
Sheet thickness 0.5-100mm

2.Technical Parameters:

Buffing wheel motor power 45kw
Workpiece feeding motor power 4kw
Spindle speed 0-2800r/min
Work efficiency 0.5-2m/min
Size 4000x3200x1800mm
Roughness Ra<0.1um
Power supply 380v/50HZ (customised)
Avaliable materials For metal with different size
Avaliable range According to your requirements
Avaliable buffing materials Abrasive belt

Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal

Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal

Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal

Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal

Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal

3.Suitable grinding and polishing material:

Belt size: 1520 × 1220mm

3.1 Abrasive belt:

Stainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer RemovalStainless Steel Plate Mirror Polishing Machine For Carbon Steel Grinding Layer Removal

3.2Surface Finish:

1. Ra≤0.1um and very good mirror finish.

2. hairline finish(Broken lines or snow line)

4.Advanages:

1

The automatic machine is an exclusive polishing system consisting 1-4 working stations; high flexibility and high product efficiency.
2

With PLC control system for high precision of control and high stability of move technology.
3 Software: Programmable, with protable handed device, contains manually mode to simulate the workmanship polishing and record the track; automatically operating model is available with pre-settled parameters program
4 Polishing pressure and wear compensation control performance: When the polishing wheel is worn out, the system can detect that the torque becomes smaller and automatically the compensation in all directions.
5

Linear speed compensation: When the outer diameter of the wheel is reduced, the system automatically increases the speed and compensation;
6

Solid or liquid polishing wax, to set up the wax spraying cycle time, frequency.
7

Full digital control, polishing program parameters can be saved and adjusted at any time.
8

CN/EN language display on Touch Panel. to set all parameters for an easy operation;fault codes display and alarm pages for quick troubles shooting and repair

Please contact us for more specifications with your inquiry today! Our honor to sever you with our best service and highest quality.

The firm was created in 2007 in HeFei City(Anhui Province), specializing in the manufacture of automatic and CNC machines for sanding and polishing.
Since its founding, solutions have been offered to the needs of customers, incorporating new technologies with a constant R & D & I, and the suitability of the equipment to the safety standards "CE".
Today ZTPolish has the trust of its clients in 30 countries, providing grinding polishing and deburring solutions for customers around the world based on the needs and experience of the Chinese market.
We offer an unequaled line of equipment allowing us to meet the needs of various sectors: automotion, aeronautics, electrical appliances and household articles, construction(aluminum profiles, locks ...); finishing plate, tube; micro-finishing, deburring, ...
