Wallpaper Rotogravure Printing Machine High Stability 3 - 50kgf Tension Range
Wallpaper Rotogravure Printing Machine High Stability 3 - 50kgf Tension Range
Wallpaper Rotogravure Printing Machine High Stability 3 - 50kgf Tension Range
Wallpaper Rotogravure Printing Machine High Stability 3 - 50kgf Tension Range
Specifications
Brand Name :
Allfine
Model Number :
LC-ASY H
Certification :
CE
Place of Origin :
Wenzhou city Pinyang
MOQ :
1
Price :
negotiation
Payment Terms :
L/C,T/T, Western Union, MoneyGram
Supply Ability :
5 sets/60 working days
Delivery Time :
60 working days
Packaging Details :
film package
colors :
10
Printing speed :
150m/min （Variable because of different ink, film, familiarity of operator）
Max. Width of printing :
1000mm
Name :
Wallpaper Rotogravure Printing Machine sugar film machine overseas services Stable and reliable
Tension control precision :
±0.5kgf
Core, I.D. of raw material :
Φ76mm
Description

Allfine Group-20 years experience Solution

1:Label production line- flexo print machine,die cutting machine,slitting machine,inspection and rewinding machine
2:Flexible package line-water bottle label PVC,heat transfer Pet, Opp, Pe etc rotogravure printer, dry laminator, PP PE film blowing machine,bag making machine
3:Decal paper,wine and smoking package-Silk screen press machinery, wicket dryer, uv dryer
4:Paper cup production line- flexo printer. die cutting machine, paper cup making machine

1: Save material 2: Improve efficiency 3:Professional tranning 4: Factory built

Partner Manager-Jack Huang
Allfine Group

Wallpaper Rotogravure Printing Machine sugar film machine overseas services Stable and reliable

rotogravure printing production line.pdf

Color quantity 10
Max. Width of printing 1000mm
Mechanical speed 180m/min
Printing speed 150m/min (Variable because of different ink, film, familiarity of operator)
Length of printing cylinder 480~1000mm
Dia. of printing cylinder Φ120mm~Φ320mm
Color control precision ±0.12mm (Variable because of different ink, film, familiarity of operator)
Max. unwind/rewind Dia.: Φ600mm
Tension range 3~50kgf
Tension control precision ±0.5kgf
Core, I.D. of raw material Φ76mm
Pneumatic source 0.6Mpa
Impression roller pressure 370kgf
Doctor blade transverse move range ±5mm
Drying mode Electrical heating
Heating power 18×10=180Kw
Mail motor 15Kw
Power consumption 231kW
Machine size 16500×3550×2850(mm)
Machine weight 26000kg
Automatic speed up/down to the target speed gradually
Max. speed limit can be set for different material or cylinder size
Idle or running status can be exchanged

Structure

  • Driving by main motor through main shaft;
  • Gear box for every printing unit with flexible connection by clutch;
  • Independent groundwork for main motor and gear down device

Parameter

  • Motor power 15kW
  • Shaft Φ40mm
  • Clutch flexible style

Feature

  1. Start at low speed with full load;
  2. Automatic speed acceleration;
  3. Integrated with the whole machine;
  4. Four stage tension control
  5. Safety light
  6. Main pneumatic source with oil/water filter

video link of LC-E model rotogravure printing machine (Aluminum foil, paper, plastic film)
https://youtu.be/NPGk7K2FOhQ

video link about LC-E model rotogravure printing machine (Export to Pakistan, print aluminum foil, BOPP, PE, PVC, PET,Paper)
https://youtu.be/lZ8PziP51Xk

Wallpaper Rotogravure Printing Machine High Stability 3 - 50kgf Tension Range

After the machine delivery to customer’s factory, we will sent engineers or technician to client’s factory, within the appointed time to install the machines and train the operator for buyers. Engineer’s salary and transportation fee from our factory to the domestic airport or station is on our account.

During the installation, customers should offer Accommodation,Round-trip tickets, Visa cost for our engineers. working time is 8 hours per day. Salary is 80-150USD per day( it depends)
