Specifications
Brand Name :
Guihe
Model Number :
TCM
Certification :
PCEC Explossion proof
Place of Origin :
China
MOQ :
1 PCS
Price :
USD99-1000/PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000PCS per month
Delivery Time :
5-7 working days
Packaging Details :
tank gauge console wooden case packing
Power supply :
AC220V,50HZ
Screen :
Full color Touch screen
Screen size :
7"
Interface :
RS232,RJ45
keywords :
tank gauge console
ATG :
probe and console
Description

Smart Tank Gauge ATG Console 7 Inch Touch Screen RS232 / RJ45 Interface Communication

TCM-1 Tank gauge smart console

● It can monitor up to 1-10 tanks and monitor the delivery conditions, it also enjoys a static leak test function.

● It can display product level, water level, temperature, volume, ullage.

● It enjoys a tank tilt compensation function.

● It can display dynamically the change of product level and water level with graphics in proportion, it features a 7 inch colored touch-screen console panel, and each interface displays 4 graphics.

● It features an audible and visual alarm function with front panel.

● It comes with two RS-232 serial interface communication ports to connect with different brand Center Console.

● It enjoys a record function, all information are stored in memory for future queries

● There is an embedded printer in it to print inventory reports, delivery reports, leak reports and shift reports.

● It can calculate volume of product by multipoint, which can fully ensure the accuracy of volume of the product.

● After connected with Center Console though internet, it can provide information in long-distance for manager to arrange the inventory.

● It can monitor the oil pump according to the product level, which can avoid the product spilled and pumpdown..

● It can connect with flow-meter to display delivery information constantly.

7 Inch Touch Screen RS232 / RJ45 Interface Communication Smart Tank Gauge ATG Console

● Specification

TCM-1 Touch Control Console
Power Supply Voltage AC120~265V 50HZ
Environmental Temperature -20℃~60℃
Environmental Humidity 20%~85%
Display Screen 7 inch real colorful touch screen
Processor / Memory High-speed embedded / ---
Printer (Optional) Embedded minitype printer
Safety Barrier Power safety barrier, communication safety barrier
Size 310x220x105 (mm)
Functions
Display English, Graph, Colored
System Language English
Monitoring Capability 10 tanks
Relay With 2 relays
Method of Communication RS-485
Tank Inventory Report Users can inquire and print inventory information at any moment.
User-defined product type supported Available
Auto Delivery Auto delivery monitoring, and reports are generated after delivery. Users can inquire and print reports.
Manual delivery Click the “start delivery”, it will create delivery report
Product Mass Calculation ---
Print Function User can print all kinds of reports
Network Function Inquiring data in long-distance through internet.
Outside Explosion-proof Ringer Avoiding the product spilled.
System Update It’s convenient to update the software and hardware.
Control the Oil Pump Avoiding the product spilled and pumpdown
Setup/Inquiry Parameter Users can setup and inquiry the parameter about the tank, hardware, product type, alarm, date, tank volume table
Automatic Gauge Display product level, water level, temperature, volume, ullage
Volume Table Edit Data input via touch screen, enjoy the import and export function.
Volume Table Calibration Use the method of Guihe Volume Table Calibration to calibrate it.
Static Leak Detection Function During the idle time of the gas station, user can do the leak detection for the thank.( Detection rate :0.38 L/H)
Dynamic Leak Detection Function ---
Alarm Audible and visual alarm and inquiry function
Shift Exchange Shift exchange function and create the report.
Interface With RS-232 serial interface communication ports

Function show:

Main interface:

7 Inch Touch Screen RS232 / RJ45 Interface Communication Smart Tank Gauge ATG Console

Print inventory report:

7 Inch Touch Screen RS232 / RJ45 Interface Communication Smart Tank Gauge ATG Console

Internet Function

1. Users can check petrol station tank gauge information on Mobile phone.

7 Inch Touch Screen RS232 / RJ45 Interface Communication Smart Tank Gauge ATG Console

2.Users can logon our remote inquiry website, enter their petrol station name and password to check their petrol station tank gauge information.

7 Inch Touch Screen RS232 / RJ45 Interface Communication Smart Tank Gauge ATG Console

7 Inch Touch Screen RS232 / RJ45 Interface Communication Smart Tank Gauge ATG Console

:
Packing:
7 Inch Touch Screen RS232 / RJ45 Interface Communication Smart Tank Gauge ATG Console
Our service

1. Provide necessary conditions for the customers visiting factory.

2. Good quality with competitive price.

3. All products have been strictly Quality Checked before shipping.

4. Free repair within 12 months.

5. Great after-sale service and offer solution within 24 hours.

6.OEM is ok.
