Intelligent Custom Phone Case Maker Machine , Low Noise Rigid Box Machine
Intelligent Custom Phone Case Maker Machine , Low Noise Rigid Box Machine
Specifications
Brand Name :
Zhongke
Model Number :
ZK-582
Certification :
CE, ISO900
Place of Origin :
China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
30% deposit+70%balance before shipment
Delivery Time :
1month after received 30% deposit
Packaging Details :
wooden pallet or wooden case
Name :
Custom Phone Case Maker Machine
Height of paper stockpile :
350mm
Speed :
1800-2700(Pcs/h)
Feature :
Low Noise
Noise level :
≤80dB
Air supply :
80(Litre/min)
Description

Intelligent Custom Phone Case Maker Machine , Low Noise Rigid Box Machine

Custom Phone Case Maker Machine Description:

Custom Phone Case Maker Machine adopts servo motor, PLC programmable controller, photoelectric tracer, touchscreen HMI and other systems, integrating mechanical, electric and pneumatic systems, making it possible that automatic paper feeding, inner board feeding, edge folding and gluing and box forming are complete in one operation. It is applicable for the production of wide-edged rigid boxes made 250-400g white cardboard, white board and corrugated paper. So it can be widely used for the production of wide-edged rigid packing boxes suitable for food, cosmetics, medicine, health care products, toys, and commodities.

Custom Phone Case Maker Machine Structural features

  1. Innovatively designed automatic filling wall for wide-edged box;
  2. servo motor, PLC programmable controller, photoelectric tracer, touchscreen HMI and other systems
  3. Infrared safety protection system to ensure the safety of operators;
  4. Automatic troubleshooting

Custom Phone Case Maker Machine Specifications

Ⅰ Ⅱ Ⅲ

Sizes of paper

A=Windth；

B=Longth

 Amin 220mm 220mm 300mm
Amax 620mm 540mm 540mm
Bmin 220mm 220mm 280mm
Bmax 740mm 630m 630mm
Cardoard blank thickness BEF 300-450g/㎡ 300-450g/㎡

Turn in depth

:R

 Rmin 20mm 20mm 20mm
Rmax 70mm 70mm 60mm

Broad-side edge width

:S

 Smin / / 6mm
Smax 10mm

Corrugated board

 Lmin 120 mm
Lmax 400 mm
Wmin 140 mm
Wmax 300 mm
Hmin 30 mm
Hmax 70 mm
Tmin 6 mm
Tmax 15 mm
Power 380V 50Hz
Noise level ≤80dB
Speed 1800-2700(Pcs/h)
Cardboard pile height 350mm
Load-bearing of cardboard laydown platform 20kg
Electrical power 19kw
Capacity of hot melt applicator 8(Litre)
Air supply 80(Litre/min)
Net weight 2600kg
Machine overall dimension 1100mmx1700mmx2200mm

Intelligent Custom Phone Case Maker Machine , Low Noise Rigid Box Machine

Note

The production speed depends on the material used, glue specifications and how skillfully the operator operates the machine.

L=Hx2+20mm.

the length of small box: L=Hx2+20mm

The forming of wide-edged boxes also depends on the material, it shall be subject to the real samples.

The specification is subject to change without notice.
