Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC
Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC
Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC
Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC
Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC
Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC
Specifications
Brand Name :
CIROLLA
Model Number :
4CM02100
Certification :
CE/CCC/ SGS
Place of Origin :
Zhejiang, China
MOQ :
500PCS
Price :
Consultation get the latest price
Payment Terms :
T/T,L/C, Western Union
Supply Ability :
50,000pcs/month
Delivery Time :
25-30days
Packaging Details :
Standard,10pcs/carton, weight 1.5kg
Motor Type :
Worm Gear reduction
Style :
Roller Shutter Motor
Operation Voltage :
24VDC
Output Power :
50W
With Electromagnetic Brake :
24VDC, 7.5Nm, 10W
Description

Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC

Specifications:

Performance data:

Type

Brush

Voltage

24VDC

Power

75W

No load Speed

95rpm

No load Current

0.5A

On load Speed

75rpm

On load Current

3.5A

Stall torque

25Nm

Gear material

DuPont 100P

Brake

24VDC,7.5Nm,10W

Protection class

IP44

Weight

1.5kg

Applications:

Roller shutters have many applications, including doors for vans, garages, kitchens, schools, prisons and warehouses. In some parts of the world, roller shutters are subsidized by local governments due to the inherent security benefits. In areas that are frequently exposed to inclement weather, roller shutters are used as a method of insulation and can protect windows against hail damage.

Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC

Description:

A roller shutter, roller door or sectional overhead door is a type of door or window shutter consisting of many horizontal slats (or sometimes bars or web systems) hinged together. The door is raised to open it and lowered to close it. On large doors, the action may be motorized. It provides protection against wind and rain. In shutter form, it is used in front of a window and protects the window from vandalism and burglary attempts.

Characteristic curves:

Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC

State

Voltage

Current

Pin

Torque

Speed

Pout

Eff

V

A

W

N.m

rpm

W

%

Speed_max

24.03

0.773

18.59

0.24

91.2

2.32

12.5

Eff_max

24.03

3.300

79.30

5.13

76.9

41.30

52.0

Pout_max

24.00

9.761

234.2

17.37

46.0

83.69

35.7

Torque_max

23.97

15.95

382.5

26.49

0.0

0.00

0.0

End

23.97

15.95

382.5

26.49

0.0

0.00

0.0

Motor Outline drawings:

Remote Control and Electromagnetic Brake Roller Shutter Garage Door Motor 24VDC

Competitive Advantage:

1) Doors are easily opened by hand by the releasing system in case of power off

2) Simple programming of operation settings

3) Built-in receiver on the control board allows you to program 20 transmitters

4) One push of the remote button and you drive straight into your garage

5) Availability of a lamp for garage lighting (10 W), the courtesy light allows you to see inside the garage

6) Automatic refund function in case of obstacles

7) Availability of automatic closing function with programmed delay time

8) Different torque to suit your garage door: 800N, 1000N, 1200N, 1500N
