50W automatic door motors with Worm Gearbox 24VDC For sectional garage door
50W automatic door motors with Worm Gearbox 24VDC For sectional garage door
50W automatic door motors with Worm Gearbox 24VDC For sectional garage door
50W automatic door motors with Worm Gearbox 24VDC For sectional garage door
Specifications
Brand Name :
CIROLLA
Model Number :
3095
Certification :
CE/CCC/ SGS
Place of Origin :
Zhejiang, China
MOQ :
500PCS
Price :
Negotiation
Payment Terms :
T/T,L/C, Western Union
Supply Ability :
50,000pcs/month
Delivery Time :
25-30days
Packaging Details :
Standard export carton or pallet,10pcs/carton, weight 1.5kg
Motor Type :
Worm Gear Reduction
Function :
Automatic Garage Door Opener
Operation Voltage :
24VDC
Output Power :
50W
Input power :
AC 220V, 50HZ
Driving force :
800N, 1000N, 1200N, 1500N
Description

50W automatic door motors with Worm Gearbox 24VDC For sectional garage door​

Suitable for Garage door opener:

Torque: 800N

Input power: AC230V, 50Hz (Or AC110V, 60Hz)

Output power: DC24V, 100W

Output torque: 8N. M

Galvanized steel, or Aluminum guide

Digital limit switch

Rolling code

For sectional garage door use

Standard equipment: 1 motor, 1 piece rack, 2 transmitters, 1 set of mounting bracket

Specifications:

Automatic Garage Door motor data:

Motor Type

Brush

Voltage

24VDC

Power

70W

No load Speed

150rpm

No load Current

1.3A

On load Speed

125rpm

On load Current

3.0A

Work torque

3Nm

Stall torque

12Nm

Gear material

Nylon

Protection class

IP44

Weight

1.5kg

Description:

A garage door opener is a motorized device that opens and closes Garage Doors. Most are controlled by switches on the garage wall, as well as by remote controls carried by the owner.In a residential garage door opener,the motor is in the box on the upper-right.Motor is the drive device of the automatic garage door system.

Applications:

Applicable to all kinds of garage door system: Chain drive and Overhead Garage door.

50W automatic door motors with Worm Gearbox 24VDC For sectional garage door50W automatic door motors with Worm Gearbox 24VDC For sectional garage door

Garage Door Opener Motor Characteristic curves:

50W automatic door motors with Worm Gearbox 24VDC For sectional garage door

Motor Outline drawings:

50W automatic door motors with Worm Gearbox 24VDC For sectional garage door

Competitive Advantage:

1) Doors are easily opened by hand by the releasing system in case of power off

2) Simple programming of operation settings

3) Built-in receiver on the control board allows you to program 20 transmitters

4) One push of the remote button and you drive straight into your garage

5) Availability of a lamp for garage lighting (10 W), the courtesy light allows you to see inside the garage

6) Automatic refund function in case of obstacles

7) Availability of automatic closing function with programmed delay time

8) Different torque to suit your garage door: 800N, 1000N, 1200N, 1500N
