60W 24V Low Noise Brush Gear Motor for Auto Sliding Door 1 Signal , 40 Pulse Honeywell Encoder
60W 24V Low Noise Brush Gear Motor for Auto Sliding Door 1 Signal , 40 Pulse Honeywell Encoder
60W 24V Low Noise Brush Gear Motor for Auto Sliding Door 1 Signal , 40 Pulse Honeywell Encoder
60W 24V Low Noise Brush Gear Motor for Auto Sliding Door 1 Signal , 40 Pulse Honeywell Encoder
Specifications
Brand Name :
CIROLLA
Model Number :
4002
Certification :
CE/CCC/ SGS
Place of Origin :
Zhejiang, China
MOQ :
300PCS
Price :
Negotiation
Payment Terms :
T/T,L/C, Western Union
Supply Ability :
50,000pcs/month
Delivery Time :
25-30days
Packaging Details :
Standard,10pcs/carton, weight 2.0kg
Motor Type :
Brush, 24VDC, 60W
Construction :
Permanent Magnet
Rotation Direction :
Reversible
Application :
Automatic sliding door
Door configuration :
Single door, Double-door
Encoder available :
1 signal, 40pulse, Honeywell brand
Description

60W 24V Low Noise Brush Gear Motor for Auto Sliding Door 1 Signal , 40 Pulse Honeywell Encoder

Description:

Unlike other electric motor types (i.e., brushless DC,AC induction), Brushed dc motors do not require a controller to switch current in the motor windings. Instead, the commutation of the windings of a BDC motor is done mechanically.

The speed of a Brushed dc motor is proportional to the voltage applied to the motor. When using digital control, a pulse-width modulated (PWM) signal is used to generate an average voltage. The motor winding acts as a low pass filter so a PWM waveform of sufficient frequency will generate a stable current in the motor winding.

Specifications:

Motor specs:

Type

Brush

Voltage

24VDC

Power

60W

No load Speed

250rpm

No load Current

0.7A

On load Speed

200rpm

On load Current

3.5A

Stall torque

12Nm

Protection class

IP44

Weight

1.5kg

Encoder Honeywell

1 signal,40pulse

Motor Outline drawings:

60W 24V Low Noise Brush Gear Motor for Auto Sliding Door 1 Signal , 40 Pulse Honeywell Encoder

Applications:

The Brush DC Motor is particularly a favorite in the automotive industry because of its simplicity and affordability. Many automotive manufacturers use them for power windows, seats, etc. However, the Brush DC Motor can be found in nearly every industry ranging from computers to manufacturing.

60W 24V Low Noise Brush Gear Motor for Auto Sliding Door 1 Signal , 40 Pulse Honeywell Encoder

60W 24V Low Noise Brush Gear Motor for Auto Sliding Door 1 Signal , 40 Pulse Honeywell Encoder

Competitive Advantage:

The Brush DC Motor has a relatively inexpensive start up cost and simple design. In some cases, the Brush DC Motor can cost half the price of their Brushless DC Motor counterparts. However, the brushes within the Brush DC Motor are apt to wear and require replacement, making it a higher-maintenance option, because of the long run costs.
