Brush 24VDC 45W BOSCH Automotive Wiper Motor IP44 50rpm 3.1A
Brush 24VDC 45W BOSCH Automotive Wiper Motor IP44 50rpm 3.1A
Brush 24VDC 45W BOSCH Automotive Wiper Motor IP44 50rpm 3.1A
Brush 24VDC 45W BOSCH Automotive Wiper Motor IP44 50rpm 3.1A
Specifications
Brand Name :
CIROLLA
Model Number :
1022
Certification :
CE/CCC/ SGS
Place of Origin :
Zhejiang, China
MOQ :
500PCS
Price :
Negotiation
Payment Terms :
T/T,L/C, Western Union
Supply Ability :
50,000pcs/month
Delivery Time :
25-30days
Packaging Details :
Standard,10pcs/carton, weight 1.5kg
Type :
Worm gear reduction
Voltage&Power :
24VDC, 45W
Structure and Working Principle :
Brush
Gear material :
Nylon
Operating Speed :
High speed& Low speed
Function :
Windshield wiper system of automobiles
Description

Brush 24VDC 45W BOSCH Automotive Wiper Motor IP44 50rpm 3.1A​

Description:

A wiper generally consists of an arm, pivoting at one end and with a long rubber blade attached to the other. A gear motor is driving device of the wiping system. The blade is swung back and forth over the glass, pushing water from its surface.

Suitable For BENZ

BOSCH: F.006 WM0.308

Applications:

Automotive mini wiper motor widely used for all kinds of cars, trucks and buses

Brush 24VDC 45W BOSCH Automotive Wiper Motor IP44 50rpm 3.1A

Specifications:

Wiper Motor Performance Data:

Type

Brush

Voltage

24VDC

Power

45W

No-load Speed

50rpm

No-load Current

0.8A

On-load Speed

35rpm

On-load Current

3.1A

Stall torque

≥30Nm

Gear material

Nylon

Protection class

IP44

Rotate direction

CW and CCW

Weight

1.5kg

Wiper Motor Characteristic curves:

Brush 24VDC 45W BOSCH Automotive Wiper Motor IP44 50rpm 3.1A

State

Voltage

Current

Pin

Torque

Speed

Pout

Eff

V

A

W

N.m

rpm

W

%

Speed_max

24.02

0.792

19.03

0.10

46.7

0.50

2.6

Eff_max

24.02

3.112

74.79

8.23

35.1

30.27

40.4

Pout_max

24.02

5.937

142.6

17.74

23.9

44.39

31.1

Torque_max

24.02

11.23

269.8

31.41

0.0

0.00

0.0

End

24.02

11.23

269.8

31.41

0.0

0.00

0.0

Wiper Motor Outline drawings:

Brush 24VDC 45W BOSCH Automotive Wiper Motor IP44 50rpm 3.1A

Competitive Advantage:

- Enhanced car styling
- Wipe angle correction - automatically delivers optimal wiping performance irrespective of windshield conditions (dry, damp, etc.)
- Electronic speed control - reduced noise at blade reversal points
- Obstacle detection - motor automatically compensates for windshield obstructions, such as snow block, and recalculates the appropriate wipe angle, limiting potential damage to the motor
