High Torque Brushed Worm Geared Motor 24VDC Permanent Magnet 50rpm
High Torque Brushed Worm Geared Motor 24VDC Permanent Magnet 50rpm
High Torque Brushed Worm Geared Motor 24VDC Permanent Magnet 50rpm
High Torque Brushed Worm Geared Motor 24VDC Permanent Magnet 50rpm
High Torque Brushed Worm Geared Motor 24VDC Permanent Magnet 50rpm
High Torque Brushed Worm Geared Motor 24VDC Permanent Magnet 50rpm
Specifications
Brand Name :
CIROLLA
Model Number :
6.409
Certification :
CE/CCC/ SGS
Place of Origin :
Zhejiang, China
MOQ :
500PCS
Price :
Negotiation
Payment Terms :
T/T,L/C, Western Union
Supply Ability :
50,000pcs/month
Delivery Time :
25-30days
Packaging Details :
Standard,10pcs/carton, weight 1.5kg
Type :
Worm gear DC Motor
Voltage&Power :
24VDC,80W
Construction :
Permanent Magnet
Structure and Working Principle :
Brushed
Operating Speed :
High Speed
Gear material :
bronze
Application :
Universal, Industrial, Household Appliances, machine power system
Description

High Torque Brushed Worm Geared Motor 24VDC Permanent Magnet

Description:

A gear motor is a type of electrical motor. Like all electrical motors, it uses the magnetism induced by an electrical current to rotate a rotor that is connected to a shaft. The energy transferred from the rotor to the shaft is then used to power a connected device.

In a gear motor, the energy output is used to turn a series of gears in an integrated gear train. There are a number of different types of gear motors, but the most common are AC (alternating current) and DC (direct current).

Applications:

Gear motors are commonly used in conveyor-belt drives, home appliances, in handicap and platform lifts, medical and laboratory equipment, machine tools, packaging machinery and printing presses.

Specifications:

Type

Brush

Voltage

24VDC

Power

80W

No load Speed

50rpm

No load Current

1.8A

On load Speed

35rpm

On load Current

6.0A

Full torque

16Nm

Stall torque

42.5Nm

Gear material

DuPont 100P

Protection class

IP44

Weight

1.5kg

High Torque Brushed Worm Geared Motor 24VDC Permanent Magnet 50rpm

State

Voltage

Current

Pin

Torque

Speed

Pout

Eff

V

A

W

N.m

rpm

W

%

Speed_max

23.96

1.818

43.58

0.09

48.2

0.48

1.1

Eff_max

23.96

6.054

145.0

16.48

36.3

62.65

43.1

Pout_max

23.95

9.737

233.3

27.98

27.2

79.69

34.1

Torque_max

23.96

15.71

376.6

42.81

5.7

25.55

6.7

End

23.96

16.05

384.8

42.17

0.0

0.00

0.0

Competitive Advantage:

One specific type of gear motor is an alternating current (AC) powered electric motor. These motors are very cost efficient and fast, and output can range anywhere between 1,200 and 3,600 revolutions per minute. Torque can be customized to synchronize with normal speeds as well as stall speeds. A small minority of gear motors are direct current (DC) powered. DC-powered motors are primarily employed in the automotive industry as important components of car construction, including windshield wiper motors, power winches on trucks, and power seat or power window motors.
