CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
Specifications
Brand Name :
Huaweishenda
Model Number :
CGF-150
Certification :
ISO/CE/HACCP
Place of Origin :
Zhangjiagang Suzhou China
MOQ :
1
Payment Terms :
L/C, T/T
Supply Ability :
10sets per month
Delivery Time :
25 working days
Packaging Details :
Wooden packing
Packing type :
3-5gallon bottle
Voltage :
220v/380v/415v
Station numbers :
Up to 10 stations
Control system :
PLC control
Machine's frame :
SS304 thickness: 2mm-6mm
Board material :
SS304 thickness: 2mm
Equipment material :
SS304 and SS316
Operating air pressure :
6-10bar
Description

Zhangjiagang CE 150 bph complete automatic water 5 gallon water bottle filling machine

Gallon Filling Machine

Gallon bottle filling machines are manufactured linear or rotary by the capacity and customer’s requirements. Filling process actualized with non contact of the bottle neck. Gallon bottles which transfered to filling machine are centred by the mechanical system and no bottle no filling. Filling pump controlled by the inverter so ensuring different filling speed in different filling level.
Feature:
* Adopt non-contact quantitative filling tech, without water overflow.
* Adopt AISI316L for part in contact with ozone water, no-dead-ends mirror polish technique, guarantee product quality.
* Reserved interface for install 100 class clean room FFU (fan filter unit).
* Adopt Simens PLC control, or same level brand product.
* FESTO air cylinder, or same level brand.
* INOXPA stainless steel filling pump, or same level brand.
* Filling volume accuracy: within ± %0.5 lt.
Project
3- 5 Gallon Water Bottling Machine
Model
QGF-100
QGF-300
QGF-450
QGF-600
QGF-900
QGF-1200
Capacity (BPH)
100
300
450
600
900
1200
Filling Heads
1
2
3
4
5
6
Air press(Mpa)
0.37
0.6
0.8
1
1.5
2.0
Power supply
1.38KW
3.8 KW
5.6KW
7.5 KW
9.75KW
12 KW
Overall dimension
3700×1300×1600
4060×1860×1600
5000×1500×2200
5400×2600×2200
8500×6000×2500
9000×6500×2800
Weight (KG)
680
1500
2100
3000
3500
4000
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
CE 150BPH 5 Gallon Automatic Filling Machines Complete Bottled Water Production Lines
