Dry Powder Mixer Blender Mixing Machine For Sauce Factory

▶Advantage:

1) Strong and fast mixing: Strong and fast mixing can be achieved due to effective drive design and variable speed blending.
2) High-degree of homogeneity: When material is added at the rate of 0.1%, the homogeneity can reach 98% in short time.
3) Heating jacket: A heating jacket can be equipped as an option in the mixing tank shell for heating or drying process. The heating medium can be steam, hot water or hot oil. Design pressure is 0.3 Mpa.
4) Liquid spray nozzle: Spray nozzle can be equipped as an option to add liquid additives which can be evenly sprayed onto the mixture.
5) Well bearing sealing: Shaft sealing is the combination of Teflon packing sealing and air-tight sealing to make sure long life-span.
6) Automatic discharging valve: The combined discharge valve is pneumatic planer flap valve. The flap plate can perfectly match the mixing tank inner wall to make sure no dead corner.

▶Working principle:

HHJ series horizontal double blade ribbon blender mixer machine consists of a U-shaped horizontal trough and a specially fabricated agitator. A ribbon agitator consists of a set of inner and outer helical agitator. The outer ribbon moves materials in one direction and the inner ribbon moves the materials in the opposite direction.The ribbon ratates at approx. 45 RPM moves materials both radially and laterally to insure thorough blends in short cycle times.

HHJ series horizontal double blade ribbon blender mixer machine is widely used to mix free-flowing powders, granules, small liquid additives to achieve paste and slurry product in food, chemical, and construction line.

▶Main Feature:

1.For mixing/blending powders, dry solids, pastes and slurries in various industries;
2. Mixing vessel volume: 300-2000L;
3. GMP design;
4. Liquid spray system and heating jacket can be equipped.
