Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding
Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding
Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding
Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding
Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding
Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding
Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding
Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding
Specifications
Brand Name :
DXH LASER
Model Number :
DXH-GW Series
Certification :
CE,FDA,SGS
Place of Origin :
Kunshan,China
MOQ :
1set
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 sets per day
Delivery Time :
7 working days
Packaging Details :
wooden package
Name :
Galvanometer Welding System
Type :
DXH-GW Series
Laser Power :
50W 100W 200W
Pulse Max Energy :
80J
Laser Wavelength :
1064nm
Laser Welding Frequency :
≤100HZ
Laser Welding Depth :
0.1-2.0mm
Output Light :
1-4 roads
Cooling Type :
Water Cooling
Total Power :
≤6KW
Machine System Size :
1540*690*1550 mm
Description

Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding

​Introduce

Scanning galvanometer fiber laser welding machine fiber transmission, uniform spot, good welding effect: After the laser transmission through the optical fiber, collimated by the collimating lens for the parallel light, and then focused on the workpiece by the implementation of welding laser welding equipment. The use of high-speed galvanometer to achieve high-speed welding: welding machine welding scanning head laser marking machine works.

Describe

Scanning galvanometer fiber laser welding machine, the use of imported optical fiber transmission, with high-speed scanning galvanometer, rapid spot welding and continuous welding, the effect of beautiful and efficient.

1. Fiber laser welding spot welding energy evenly, with the best welding characteristics required spot.

2. Fiber laser welding machine to adapt to a variety of complex welds, a variety of devices, spot welding, as well as within 1mm seam welding seam.

Automatic translation of the table, to achieve double-bit operation: Under the welding head with a one-dimensional translation table, through a dedicated welding software multi-file marking function can achieve double-bit operation, the staff can work both hands up and down welding, greatly increased The overall welding efficiency, the welding head fixed in the vertical direction of the installation of one-dimensional platform, through the front panel of the lift button, you can quickly and easily adjust the level of the laser head, making the adjustment of the laser focus more easily and quickly.

3. Fiber laser welding machine to install high-speed digital scanning galvanometer to achieve high-speed spot welding and continuous welding, improve efficiency.
4 fiber laser welding machine imported from the United Kingdom ceramic condenser cavity, corrosion resistance, high temperature, cavity life (8-10) years, xenon lamp life of 8000000 times

5. Rich I / O interface, the user can easily control the welding machine.

6. The key components are imported parts abroad, to ensure product quality.

7. By energy splitting or time-splitting, simultaneous welding or sub-time welding can be achieved.

8. Compared with the traditional hard-light output system, it can increase the machining freedom, and can process multiple beams simultaneously and multi-station machining, providing the conditions for more precise welding.

Customization of special automated fixture, to achieve mass production of products.

Application

Mainly for thin-walled materials, precision parts of the welding, can be spot welding, butt welding, welding, welding, etc., with a high aspect ratio, weld width, heat affected zone, deformation, welding speed, welding Smooth, beautiful, high quality weld, no pores, can be precisely controlled, focused light spot, easy to automate the transmission of optical fiber. In the battery industry, IT industry, electronic devices, optical communications industry, sensor industry! Hardware welding

Samples

Galvanometer Welding System / Laser Welding Machine For Mobile Phones IT Industry Applied / Spot Welding

Technical Parameters

Technology Specifications (for reference)

Max Laser Power

500W

Single Pulse Max Capacity

120J

Laser Wavelength

1064nm

Laser Welding Frequency

≤100HZ

Laser Welding Depth

0.1-3.5mm

Pulse Width

0.1-50ms

Control System

IPC/CNC2000

Spot Size

0.2-2mm

Standard workbench

300*200mm/Optional

Positioning System

Red Indicator/CCD/Microscope

Power Requirement

380V/50HZ/40A

Cooling Type

With circulating water cooling

Power Consumption

15kw

Scanning Fiber Laser Welding System Pre-Sale and After-Sale Service:


Pre-sale Service


1. Welcome to send sample material to us for testing laser marking engraving effect for you.


2. We offer pictures, videos and other relevant documents for you to know more about the machine.


3. We are online and would respond fast to answer all your questions.


4. If you have chance visiting China, you are warmly welcome to visit our factory.


After-sale Service


1. Fiber Laser Welding Machine‘s warranty is 1 year. Any parts have a quality problem during the warranty period, We will send you a new replacement for free. And Customer affords the replacement shipping cost.


2. The training video, detailed manual, and catalog sent with the machine. The customer could study the operation of the machine by watching the clear training video. And the use of laser marking engraving machine will be very easy.


3. If there is a technical problem or new inquiry, Mactron?has a fast response to?service support by online or email even if need by the phone call.


4. Professional technical support and after sales following up. A free software update.
