Precision Fiber Metal Tube Laser Cutting Machine Water Cooling FDA Certification
Precision Fiber Metal Tube Laser Cutting Machine Water Cooling FDA Certification
Specifications
Brand Name :
DXH Brand
Model Number :
YC-ESM8
Certification :
CE,SGS,FDA
Place of Origin :
Kunshan
MOQ :
1set
Price :
USD20000/set
Payment Terms :
T/T
Supply Ability :
10sets per day
Delivery Time :
15 work days
Packaging Details :
Wooden Package
Condition :
New
Graphic format supported :
PLT,AI,DXF,DST,BMP
Laser power :
200W（100W、150W、250W、300W)
Product name :
High presicion Fiber tube laser cutting machine
Function :
Cutting Metal Materials
Cooling mode :
Water Cooling
Description

Precision Fiber Metal Tube Laser Cutting Machine Water Cooling FDA Certification

Feature

1. Materail of cutting platform ,the cutting platform is made of granite ,column cantilever structure make sure high precision and more stability


2. Working platform : The machine is working by high precision pipe processing cutting platform ,the cutting platform is inculding 360 degree rotary axis which can customization depend on client's requirement


3. Laser master: This model aslo can working with every high performance optical fiber master,which specilized for cutting any thinness metal pipe


4. Laser cutting header: The laser cutting head can be customized by client requirement


5. CNC software system:All the axis control by driving motor and servo motor ,the system support 2D image and easy to operation


6. Advantage:The machine offer engine pipe automatic rotary processing and high precision fixture rotary cutting ,provide air-extracter for dust clean.

Samples

Precision Fiber Metal Tube Laser Cutting Machine Water Cooling FDA Certification

Technical Parameters

Max Running Speed 300mm/s(X)；100mm/s(Z)；600rpm(θ)；
Position Precision ±2um(X)；±3um(Z)；±15arcsec(θ)；
Repeat Position Precision ±0.5um(X)；±1um(Z)；±3arcsec(θ)；
Minimum cut seam width 15um(Kerf:16um~25 um)；
Processing of materials 304,316L, Ni-Ti,L605
Length of tube blank <2.5m
Processing of wall thickness 0~0.5±0.02 mm；
Processing diameter Φ0.1~Φ7.5±0.02 mm；
Single processing range 0～300mm(longer products will be processed by piecewise splicing)
Laser Source Fiber Laser Source
Laser Wavelength 1064nm± 10nm；
Laser Power 200W(100W,150W,250W,300W)
Power Supply 220V±10%,50Hz；AC 15A
Size About 1200mmx1300mmx1700mm
Weight About 1500Kg
Compatible File Format DXF,DWG
