Portable Butt Wire Mesh Spot Welding Machine Long Arm Wires 1 - 3mm Stable Performance
Portable Butt Wire Mesh Spot Welding Machine Long Arm Wires 1 - 3mm Stable Performance
Portable Butt Wire Mesh Spot Welding Machine Long Arm Wires 1 - 3mm Stable Performance
Portable Butt Wire Mesh Spot Welding Machine Long Arm Wires 1 - 3mm Stable Performance
Portable Butt Wire Mesh Spot Welding Machine Long Arm Wires 1 - 3mm Stable Performance
Portable Butt Wire Mesh Spot Welding Machine Long Arm Wires 1 - 3mm Stable Performance
Portable Butt Wire Mesh Spot Welding Machine Long Arm Wires 1 - 3mm Stable Performance
Portable Butt Wire Mesh Spot Welding Machine Long Arm Wires 1 - 3mm Stable Performance
Specifications
Brand Name :
Chengke
Model Number :
CK-SW
Certification :
ISO
Place of Origin :
Heibei China
MOQ :
1 Set
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50 Sets/Month
Delivery Time :
15 Workdays
Packaging Details :
No
Condition :
New
Input Voltage :
380V
Power :
100KVA
Usage :
Rebar Butt Welding
After-sales :
overseas service provided
Color :
Blue,white
Description

1 - 3mm Steel Wire Small Size Portable Butt Welding Machine Stable Quality

description

Mainly used for butt welding variety of steel and Non-ferrous metals,such as low carbon steel, carbon steel,

stainless steel and nonferrous metal round wire, flat wire, round steel, flat steel, rebar steel, and so on;

Features

1. it is one kind of manual lever pressuring type of welding,the welding pressure is by way of manual control lever on the workpiece to achieve the butt flash butt welding and resistance butt welding;

2. Because this kind of butt welding machine no need air compressor, simple operation,easy to move,stable quality,therefore widely used for the field of construction,express way,bridge,steel wire drawing plant,cement prefabricated factory,metal products and so on.Especially suitable for using in the construction field and country side.

Specification

Machine Model

Input Voltage

(V)

Input

Power

(KVA)

Secondary

Voltage

(V)

Welding

Surface

(mm2)

Input

Current

(A)

Power Regulate

Range
CK-1KVA 220V 1 0.6-2 7 3 1-8Taps
CK-2KVA 220V 2 1-2 15 6 1-8Taps
CK-3KVA 220V 3 1.5-3 28 9 1-8Taps
CK-10KVA 380V 10 1.7-3.5 50 30 1-8Taps
CK-25KVA 380V 25 1.76-3.52 110 65 1-8Taps
CK-75KVA 380V 75 3.58-7.16 320 198 1-8Taps
CK-100KVA 380V 100 3.96-7.98 500 263 1-8Taps
CK-150KVA 380V 150 4.13-8.26 1250 395 1-8Taps

advantages


1. Punctual: Have your orders met with the latest delivery?

We are a manufacturer with so many advanced and new machines.

It ensures we have the ability to carry out the production schedual for punctual delivery.

2. 17-year production experience. We have over 17 years exprerience in this industry.

That means we can preview the problems for the orders and production.

Therefore, it will make sure to deduce the risk of bad situation to happen.
