380V 3Phz Automatic Water Bottle Filling Machine Rotary Type
380V 3Phz Automatic Water Bottle Filling Machine Rotary Type
380V 3Phz Automatic Water Bottle Filling Machine Rotary Type
380V 3Phz Automatic Water Bottle Filling Machine Rotary Type
380V 3Phz Automatic Water Bottle Filling Machine Rotary Type
380V 3Phz Automatic Water Bottle Filling Machine Rotary Type
Specifications
Brand Name :
Aquatrin
Model Number :
CGF
Certification :
ISO CE
Place of Origin :
China
MOQ :
1unit
Price :
USD12000-50000 1Set
Payment Terms :
L/C, T/T
Supply Ability :
10units per month
Delivery Time :
45days
Packaging Details :
wooden package
Type: :
Filling Machine
Automatic Grade: :
Automatic
Voltage: :
380V 3Phz 50~60Hz
Bottle type: :
PET Plastic Bottle
After Warranty Service: :
Video technical support
Driven Type: :
Electric
Advantage: :
High Efficiency
Model Number: :
CGF24-24-8
Description

Drinking Water Bottle Filling Machine Rotary Bottle Filling Machine

1. The drink water bottling filling machine/line has a compact structure, complete control system, convenient operation and high degree of automation.
2. The technology of direct connection between the air-sending road and the bottle-into-wheels eliminates the bottle-screws and the conveyor chain. It is simple and easy to change bottle types. After the bottle enters the machine through the air duct, it is sent directly to the bottle rinser by the steel bottle dial wheel (card bottleneck method).
3. The parts in contact with the materials are made of imported high-quality stainless steel. There are no dead corners and easy to clean.
4. The use of high-precision, high-speed quantitative filling valve, liquid level accuracy without fluid loss, ensure excellent filling quality.
5. The capping head uses a constant torque device to ensure capping quality.
380V 3Phz Automatic Water Bottle Filling Machine Rotary Type

Machine Parameter

Model
CGF
8-8-4
CGF
14-12-5
CGF
16-16-5
CGF
20-20-6
CGF
24-24-8
CGF
32-32-10
CGF
40-40-12
CGF
50-50-15
Production capacity
500ml(B/H)
3000-4000
4000-5000
7000-8000
10000-12000
12000-15000
15000-18000
18000-20000
20000-24000
Filling precision
≤±3mm(Liquid level positioning)
Suitable bottle
Round or square shaped bottle
PET bottle
Bottle Diameter:Ф50～Ф100 Bottle Height:150mm～330mm
Suitable cap standard
Plastic Screw Cap
Rinsing water pressure(MPa)
0.2～0.25
Rinsing water consumption(Kg/h)
500
600
700
800
1500
1800
2500
3000
Air source pressure(MPa)
0.4
Air consumption(m3/min)
0.3
0.3
0.3
0.3
0.4
0.4
0.5
0.55
Total Power(Kw)
2.5
3
3.3
3.8
4.2
5.6
6.4
9.8
Overall Dimensions(L×W×H)(mm)
1950x1450×2350
2260×1600×2350
2350×1900×2350
2900×2200×2400
3300×2300×2400
4100×2850×2400
4250×3200×2400
5750×3750×2400
Total Weight(Kg)
2500
2800
3000
4000
5000
6500
8000
9000

380V 3Phz Automatic Water Bottle Filling Machine Rotary Type

380V 3Phz Automatic Water Bottle Filling Machine Rotary Type

380V 3Phz Automatic Water Bottle Filling Machine Rotary Type

380V 3Phz Automatic Water Bottle Filling Machine Rotary Type
