Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating
Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating
Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating
Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating
Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating
Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating
Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating
Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating
Specifications
Brand Name :
Aquatrin
Model Number :
CGF
Certification :
ISO CE
Place of Origin :
China
MOQ :
1unit
Price :
USD25000-60000 1Set
Payment Terms :
T/T
Supply Ability :
10units per month
Delivery Time :
45days
Packaging Details :
wooden package
Name :
blowing machine
Automatic :
Full automatic
After-sales Service Provided: :
Engineers available to service machinery overseas
PLC Brand: :
MITSUBISHI
Rotary Cylinder Brand: :
FESTO
Heating method: :
electric cycle heating
Service: :
Full technical training
Description

Good Quality High Speed Full Automatic Blow Molding Machine

Product Description
K series is a stable two-step blow-down stretch automatic blowing machine.It can be used from 4 cavity to 12 cavity with a speed of 1500 bottles per hour (750 ml plastic bottles),max volume 2L plastic bottle,suitable for blowing any kind of carbonated beverage bottle,sparkling beverage bottle,pure water bottle, mineral water bottle,fruit juice beverage bottle,cosmetic bottles,large diameter bottles, high temperature resistance bottles and other packaging bottles.
Specification
Model K6
Bottle type specification
Cavity
6
Max.volume
2L
Bottle mouth maximum overall diameter
28-30mm
Bottle biggest diameter
100mm
Bottle maximum height
330mm
Capacity specification
Theory output
9000~12000BPH
Bottle type volume
500ML
Bottle type weight
17g
Bottle type
Round
Power specification
Light tube quantity
32pcs
Light tube power
1.25KW
Maximum heating power
40KW
All electric machine installation
49KW
Actual consumption
30%--60%
Air pressure specification
Work pressure
5-6kg/cm2
Blow bottle pressure
25-45kg/cm2
Higher -pressure gas consumption
8000Ltr/min
Air pressure specification
Work pressure
5-6 kg/cm2
Temperature range
10℃
Consumption
8000kcal/hr
Forzen water flow
120L/min
Machine specification
Machine size
5.5x1.8x1.9
Machine weight
6.1ton

3. Machine Details

Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating

Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating

Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating

Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating

Two Step 6 Cavity PET Stretch Blow Moulding Machine Electric Cycle Heating

After Sale Sercive
1.Installation, debug
We will arrange seasoned technician for debug and test production at the same time make the equipment reach the rated producing
capacity of the line.
2. Training
Our company offer technology training to customer. The content of training is structure and maintenance of equipment, control and
operation of equipment. After training, the technician of buyer could master the operation and maintenance, could adjust the process and treat different failures.
3.the sample service
1'We can send you the video of the running machine.
2'You are welcome to come to visit our factory,and see the machine running.
4.We can design the machines according your requirements,at the same time we will give you our professional suggestion,as you know,we have been in this industry for 12 years.
5.well-trained & experienced staff are to answer all your inquiries in English and Chinese
6 .12 Months guarantee and life-long technical support.
7.Your business relationship with us will be confidential to any third party.
8. Good after-sale service offered, please get back to us if you got any questions.
