6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
Specifications
Brand Name :
Aquatrin
Model Number :
CGF
Certification :
ISO CE
Place of Origin :
China
MOQ :
1unit
Price :
USD12000-50000 1Set
Payment Terms :
L/C, T/T
Supply Ability :
10units per month
Delivery Time :
45days
Packaging Details :
wooden package
Type: :
Filling Machine
Bottle type: :
PET Plastic Bottle
Usage: :
Beverage Filling Packaging
Capacity: :
4000-24000BPH
Marketing Type: :
Ordinary Product
Filling Accuracy: :
99%
Description

Middle Capacity 8000bph Mineral/Pure Water Filling Machine / Line Price

Bottled water plant machinery:
1. (Making bottle) Full automatic bottle blow machine or Semi automatic bottle blow machine
2. (Water Filtration) RO water purification machine / UF mineral water filtration machine.
3. (Filling water into bottle) Bottle washing filling and capping machine.
4. (Labeling bottle water) Shrink sleeve labeling machine or Sticker labeling machine.
5. (Printing the date on the bottle water) Date printing machine.
6. (package the bottle water) Full automatic shrink wrapping packing machine or Semi automatic shrink wrapping packing machine /Carton box packing machine

6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW

6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW

Product Detail
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
18 pcs washing heads
18 pcs washing heads, The inside and outside of the bottle can be cleaned at the same time


18 pcs filling heads

High precision filling nozzle, PLC variable signal control, All 304 stainless steel contact parts & liquid tank, easy to clean No
bottle no filling
6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW


6pcs capping heads
Intelligent calculation of the torque to ensure that the cap will not be twisted or slipped Grab the cap vertically, there is no
reverse cap and leakage cap
Product Specifications
Rinsing head
18pcs
Filling head
18pcs
Capping head
6000BPH@500ml bottle
Suitable bottle
Φ:50-95mm,H:140-320mm,Volume:240-1500ml
Air pressure
0.4MPa
Air consumption
0.15m3/min
Rinsing water pressure
0.2-0.25MPa
Water consumption for rinsing
0.5 ton/h
Filling
3000 ton/h
Power
3.5KW
Name
Original
Main Motor
China
Frequency converter
Germany
PLC Control
Germany
Mechanic overload
France
Pneumatic components
Taiwan
Photocell switch
Japan
Breakers
France
Touch screen
Germany
Proximity switch
Japan

6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW

Choose your production output per hour:
12-12-1 Bottle Water Washing Filling Capping Machine,Production:1000-2000 bottles per hour.
8-8-3 Bottle Water Washing Filling Capping Machine,Production:2000-3000 bottles per hour.
14-12-5 Bottle Water Washing Filling Capping Machine,Production:4000-5000 bottles per hour.
16-16-5 Bottle Water Washing Filling Capping Machine,6000-8000 bottles per hour.
24-24-8 Bottle Water Washing Filling Capping Machine,8000-9000 bottles per hour.
32-32-8 Bottle Water Washing Filling Capping Machine,10000-12000 bottles per hour.
40-40-10 Bottle Water Washing Filling Capping Machine,13000-15000 bottles per hour.
Type
Washing Nos
Filling Nos
Capping Nos
Capacity
XGF 8-8-3
8
8
3
2000BPH
XGF 14-12-5
14
14
5
5500BPH
XGF 16-16-5
16
16
5
8000BPH
XGF 24-24-8
24
24
8
12000BPH
XGF 32-32-8
32
32
8
15000BPH

6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW

6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW

6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW

Packaging&shipping

Packaging

As usual, we adopt wooden case as package type. It's suitable for long-distance transport.According to customers' special demand, we could adopt sheet iron case and so on.

Shipping

Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.

6000Bph 500ml Liquid Filling Equipment Water Capping Filling Machine 3.5KW
