12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200
12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200
Specifications
Brand Name :
Aquatrin
Model Number :
QGF
Certification :
ISO CE
Place of Origin :
China
MOQ :
1unit
Price :
USD2000-60000 1Set
Payment Terms :
T/T
Supply Ability :
10units per month
Delivery Time :
45days
Packaging Details :
wooden package
Name :
5 gallon filling machine
Bottle size: :
1- 5gallon or 1L~20L
Control: :
PLC (MITSUBISHI)
Processing: :
Rinsing, bottling ,capping
Name: :
5 gallon water filling machine
Function: :
Washing+filling+capping
Core Components: :
PLC, Gear, Gearbox
Bottle material: :
PC/PET Barrel
Description
5 gallon water filling machine is used to produce 5 gallon drinking water.

product description:

5 gallon water filling machine is the core equipment in the 5 Gallon barreled drinking water producing line. It is the ideal equipment for mineral water, distilled water and purified water producing process.

Features of 5 gallon water filling machine:

1.Medicine water tank with temperature control system.

2.Low level automatic alarm devices for each rinsing water tank.

3.Rinsing position can be made by customer’s requirement.

technical parameter:

Production capacity 1200BPH
Heating Power 12kw (HEATING)
Other electricity consumption 6 kw
Total station 26
Overall size(mm) 6050×2300×2200(L×W×H)
Gas consumption 0.6m3/min
Pressure 0.6Mpa
Washing tank 3sets
Washing pump 4sets
Tube size(skeleton) 75*45*3mm SUS304
Material SUS304 thickness1.5mm


Main brand

Water pump Nanfang
Cylinder AirTAC
Photoelectricity Omron
Spray nozzle Copy the USA spray technology
Lye water tank SUS304
Thermostat Joint venture
Pneumatic component Airtac
Product Description

Product Application.

1/Auto Bottle Uploader
2/ Decapping Machine
3/ Outside Brusher
4/ Inside Brusher
5/Rinsing Filling Capping Machine <with Cap Elevator and Sterilization System>
6/ Light Inspector+Cap Seal Shrink Machine
7/ Finished Products

Containers and Specifications
Project Name:
Full Automatic Complete 60-1200BPH 3-5 Gallon Barrel Filling Production Line
Mineral Water /
Pure Water
Material
Shape
Filling volume
Filling Type
PC / PET
Round or Square
3 - 5 Gallon
Gravity filling
Normal temperature
Adjustable Specifications
of
Bottle Type
Size of Barrel : ф276×490mm
Customers need to buy additional change-over parts for the different bottles.
If using square bottles, then bottle separating system will be added.
Container Label
Sticker Label / Shrink Wrap Label / Prinetr Label
User Ambient Conditions
Temperature:10~40℃;Humidity:No dew
User Electrical Supply Specification
Voltage:380V±5%, 3phase; Frequency:50HZ±1%

Main Features.

QGF type barreled water producing line is the core equipment in the 5 Gallon barreled drinking water producing line. It is the ideal equipment for mineral water, distilled water and purified water producing process. The machine is made of excellent stainless steel with the advantage of easily-rinsing and corruption-resistance. The main electrical parts adopt products with brand of SIEMENS and OMRON. Pneumatic parts adopt products with brand of AIRTAC. Both the inner and outer shower nozzle for washing barrel adopt the special technology equipment from American sprayer company. The machine works reliably and efficiently based on the compact structure and high automatic technology. It is the fully automatic barreled water producing equipment combined with machine, electronic and pneumatic components.

Automatic Bottle Loading System

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

Model: IBW-8/16

Function: wash & disinfect the internal 5 gallon bottle with hot alkali water, detergent

water,cycle water, production water

Technical Parameter

  • Washing capacity: 1200 bottles per hour

  • Washing station: 8pcs

  • Washing stops: 16pcs

  • Each washing stops washing time: 18 seconnds

  • Washing tank: 4pcs ( hot hot alkali water tank, detergent water tank, cycle water tank, production water tank)

  • Washing pump 4pcs fixed with each water tank.

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

Water Filler

Model: RF-8E

Function: to fill the production water into empty bottle,Technical Parameter:

  • Filling Nozzle: 8pcs SUS304

  • Filling Capacity: 1200 bottle per hour

  • Suitable to bottle dimension: 3,5,6 gallon bottle

  • Drive motor power 2.2kw 1pc

  • Dimension: 1800×1200×2500mm

  • Weight: 600kg

Feature:

  • Gravity style filling nozzle, high filling precision

  • Under PLC control, full-automatic working

  • SUS304 water bowl, inside polish

  • SUS304pipeline, valve and other contact parts

  • Emergency stop button

  • Automatic alarm system when accident

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

Caps Chain Plate Capper

capping the bottle by chain plate station

Techincal Parameter:

Capping capacity: 1200BPH

Feature:

Automatic caps arranging,caps washing and caps delivery.

Lack of caps automatic start, full of caps automatic start

Chain plate capping station, steadily & smoothly

SUS304 pipeline, valve and other liquid contacts parts

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

Caps Elevator

Model: CF-1

Function: to convey the caps to the Capper‘s caps container full-automatically

304 stainless steel construction

Heavy duty convey motor 1pc

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

No 1. Cap Decapper

Model: DP-2

Function: to remove the caps that leave the 5gallon bottle that after used Technical Parameter

  • Decapping heads: 2pcs

  • Decapping Capacity: max 1200 bottle per hour

  • Machine size: 800×500×1750mm Machine

  • Weight: 150Kg

  • Air required 0.4cbm/minite compressed @ pressure 0.6—0.8Mpa

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

No 2. Brush External Bottle Washer

Model: BEW-2T

Function: clean the outside body of 5 gallon bottles with brush and water Technical Parameter

  • Production capacity: 1200bottle per hour

  • Brushing washing time: 8 Seconds

  • Water tank: 1pc with volume 120liter

  • Drive motor power: 0.75KW

  • Washing pump: 2pcs, each washing pump power: 0.37kw

  • Dimension:2000×1250×1750mm

  • Weight: 700kg

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

Model: SL-30E 5 gallon labeling machine

Main Parameter of Automatic Sleeve Labeling Inserting Machine:

Model SL-30E
Labeling Speed ( capacity) Max1,600 bottle per hour
Suitable to Bottle Diameter 3,5,6gallon bottle
Suitable to Bottle Height (mm) Max. 450
Suitable to bottle diameter(mm) Max.270
Suitable to Label length(mm) 35~100mm
Label thickness 0.035~0.08mm
Paper pipe interior diameter 3~10mm adjustable
Power 2.2kw
Machine Dimension 1500(L)* 950(W) * 2000(H) mm
Weight 350kgs

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200

12kw Heating 0.6m3/ Min Gas Water Bottling Machine 1200BPH QGF-1200
