100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle
100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle
100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle
100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle
Specifications
Brand Name :
Aquatrin
Model Number :
QGF
Certification :
ISO CE
Place of Origin :
China
MOQ :
1unit
Price :
USD2000-60000 1Set
Payment Terms :
T/T
Supply Ability :
10units per month
Delivery Time :
45days
Packaging Details :
wooden package
Type: :
Filling Machine
Name :
5gallon filling machine
Packaging Type: :
Barrel, Bottles
Machine Material: :
Stainless Steel SUS 304
Bottle Material: :
PC/PET/PP
capacity :
100-1200BPH
Dimension(L*W*H): :
4470*1800*1100mm
Usage: :
Water Filling 5 Gallon
Description
Product Description

Whole Water Bottle Filling and Packing Line

1. Automatic Washing

2. Automatic Filling
3. Automatic Capping
4. Water Treatment Plant
5. Removing cap machine

6. Inside&Outside Brushing Machine
7. Date and Batch Coding Machine
8. Sleeve Shrink Labeling Machine
9. PET Bottle Blowing System
10. Compressor Station





5 Gallon Water filling machine is designed for big bottle filling from 3 gallon to 5 gallon .

Water Bottle Filling Machine/Water Bottle Filler
Model
Full Automatic(PLC Control)
Capacity
100 to 1200 Bottles Per Hour
Bottle Type
PET Bottle/PE Bottle
Volume 10L-20L/3-5 Gallon
Filling Liquid
Mineral water/Pure water

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

Automatic Bottle Loading System

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

Model: IBW-8/16

Function: wash & disinfect the internal 5 gallon bottle with hot alkali water, detergent

water,cycle water, production water

Technical Parameter

  • Washing capacity: 1200 bottles per hour

  • Washing station: 8pcs

  • Washing stops: 16pcs

  • Each washing stops washing time: 18 seconnds

  • Washing tank: 4pcs ( hot hot alkali water tank, detergent water tank, cycle water tank, production water tank)

  • Washing pump 4pcs fixed with each water tank.

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

Water Filler

Model: RF-8E

Function: to fill the production water into empty bottle,Technical Parameter:

  • Filling Nozzle: 8pcs SUS304

  • Filling Capacity: 1200 bottle per hour

  • Suitable to bottle dimension: 3,5,6 gallon bottle

  • Drive motor power 2.2kw 1pc

  • Dimension: 1800×1200×2500mm

  • Weight: 600kg

Feature:

  • Gravity style filling nozzle, high filling precision

  • Under PLC control, full-automatic working

  • SUS304 water bowl, inside polish

  • SUS304pipeline, valve and other contact parts

  • Emergency stop button

  • Automatic alarm system when accident

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

Caps Chain Plate Capper

capping the bottle by chain plate station

Techincal Parameter:

Capping capacity: 1200BPH

Feature:

Automatic caps arranging,caps washing and caps delivery.

Lack of caps automatic start, full of caps automatic start

Chain plate capping station, steadily & smoothly

SUS304 pipeline, valve and other liquid contacts parts

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

Caps Elevator

Model: CF-1

Function: to convey the caps to the Capper‘s caps container full-automatically

304 stainless steel construction

Heavy duty convey motor 1pc

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

No 1. Cap Decapper

Model: DP-2

Function: to remove the caps that leave the 5gallon bottle that after used Technical Parameter

  • Decapping heads: 2pcs

  • Decapping Capacity: max 1200 bottle per hour

  • Machine size: 800×500×1750mm Machine

  • Weight: 150Kg

  • Air required 0.4cbm/minite compressed @ pressure 0.6—0.8Mpa

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

No 2. Brush External Bottle Washer

Model: BEW-2T

Function: clean the outside body of 5 gallon bottles with brush and water Technical Parameter

  • Production capacity: 1200bottle per hour

  • Brushing washing time: 8 Seconds

  • Water tank: 1pc with volume 120liter

  • Drive motor power: 0.75KW

  • Washing pump: 2pcs, each washing pump power: 0.37kw

  • Dimension:2000×1250×1750mm

  • Weight: 700kg

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

Model: SL-30E 5 gallon labeling machine

Main Parameter of Automatic Sleeve Labeling Inserting Machine:

Model SL-30E
Labeling Speed ( capacity) Max1,600 bottle per hour
Suitable to Bottle Diameter 3,5,6gallon bottle
Suitable to Bottle Height (mm) Max. 450
Suitable to bottle diameter(mm) Max.270
Suitable to Label length(mm) 35~100mm
Label thickness 0.035~0.08mm
Paper pipe interior diameter 3~10mm adjustable
Power 2.2kw
Machine Dimension 1500(L)* 950(W) * 2000(H) mm
Weight 350kgs

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle

100BPH 5 Gallon Water Filling Machine ISO PLC For PP Bottle
